Revision 1
Cell Signaling Technology

Orders: 877-616-CELL (2355) [email protected]

Support: 877-678-TECH (8324)

Web: [email protected] cellsignal.com

3 Trask LaneDanversMassachusetts01923USA
For Research Use Only. Not for Use in Diagnostic Procedures.
Applications:

WB, IHC-Bond, IHC-P, IF-F, IF-IC

REACTIVITY:

H M R

SENSITIVITY:

Endogenous

MW (kDa):

180-220

Source/Isotype:

Rabbit IgG

UniProt ID:

#P12036

Entrez-Gene Id:

4744

Product Information

Product Usage Information

This product is the carrier free version of product #30564. All data were generated using the same antibody clone in the standard formulation which contains BSA and glycerol.

This formulation is ideal for use with technologies requiring specialized or custom antibody labeling, including fluorophores, metals, lanthanides, and oligonucleotides. It is not recommended for ChIP, ChIP-seq, CUT&RUN or CUT&Tag assays. If you require a carrier free formulation for chromatin profiling, please contact us. Optimal dilutions/concentrations should be determined by the end user.

Formulation

Supplied in 1X PBS, BSA and Azide Free.

For standard formulation of this product see product #30564

Storage

Store at -20°C. This product will freeze at -20°C so it is recommended to aliquot into single-use vials to avoid multiple freeze/thaw cycles. A slight precipitate may be present and can be dissolved by gently vortexing. This will not interfere with antibody performance.

Specificity / Sensitivity

Neurofilament-H (E7Z7G) Rabbit mAb (BSA and Azide Free) recognizes endogenous levels of total Neurofilament-H protein. Non-specific staining was observed in some tumor and normal epithelium by immunohistochemistry.

Species Reactivity:

Human, Mouse, Rat

Source / Purification

Monoclonal antibody is produced by immunizing animals with a synthetic peptide corresponding to residues surrounding Lys996 of human Neurofilament-H protein.

Background

The cytoskeleton consists of three types of cytosolic fibers: actin microfilaments, intermediate filaments, and microtubules. Neurofilaments are the major intermediate filaments found in neurons and consist of light (NFL), medium (NFM), and heavy (NFH) subunits (1). Similar in structure to other intermediate filament proteins, neurofilaments have a globular amino-terminal head, a central α-helical rod domain, and a carboxy-terminal tail. A heterotetrameric unit (NFL-NFM and NFL-NFH) forms a protofilament, with eight protofilaments comprising the typical 10 nm intermediate filament (2). While neurofilaments are critical for radial axon growth and determine axon caliber, microtubules are involved in axon elongation. PKA phosphorylates the head domain of NFL and NFM to inhibit neurofilament assembly (3,4). Research studies have shown neurofilament accumulations in many human neurological disorders, including Parkinson's disease (in Lewy bodies along with α-synuclein), Alzheimer's disease, Charcot-Marie-Tooth disease, and Amyotrophic Lateral Sclerosis (ALS) (1).

  1. Al-Chalabi, A. and Miller, C.C. (2003) Bioessays 25, 346-55.
  2. Cohlberg, J.A. et al. (1995) J Biol Chem 270, 9334-9.
  3. Hisanaga, S. et al. (1994) Mol Biol Cell 5, 161-72.
  4. Sihag, R.K. et al. (1999) J Neurochem 72, 491-9.

Species Reactivity

Species reactivity is determined by testing in at least one approved application (e.g., western blot).

Applications Key

WB: Western Blotting IHC-Bond: IHC Leica Bond IHC-P: Immunohistochemistry (Paraffin) IF-F: Immunofluorescence (Frozen) IF-IC: Immunofluorescence (Immunocytochemistry)

Cross-Reactivity Key

H: human M: mouse R: rat Hm: hamster Mk: monkey Vir: virus Mi: mink C: chicken Dm: D. melanogaster X: Xenopus Z: zebrafish B: bovine Dg: dog Pg: pig Sc: S. cerevisiae Ce: C. elegans Hr: horse GP: Guinea Pig Rab: rabbit All: all species expected

Trademarks and Patents

Cell Signaling Technology is a trademark of Cell Signaling Technology, Inc.
All other trademarks are the property of their respective owners. Visit cellsignal.com/trademarks for more information.

Limited Uses

Except as otherwise expressly agreed in a writing signed by a legally authorized representative of CST, the following terms apply to Products provided by CST, its affiliates or its distributors. Any Customer's terms and conditions that are in addition to, or different from, those contained herein, unless separately accepted in writing by a legally authorized representative of CST, are rejected and are of no force or effect.

Products are labeled with For Research Use Only or a similar labeling statement and have not been approved, cleared, or licensed by the FDA or other regulatory foreign or domestic entity, for any purpose. Customer shall not use any Product for any diagnostic or therapeutic purpose, or otherwise in any manner that conflicts with its labeling statement. Products sold or licensed by CST are provided for Customer as the end-user and solely for research and development uses. Any use of Product for diagnostic, prophylactic or therapeutic purposes, or any purchase of Product for resale (alone or as a component) or other commercial purpose, requires a separate license from CST. Customer shall (a) not sell, license, loan, donate or otherwise transfer or make available any Product to any third party, whether alone or in combination with other materials, or use the Products to manufacture any commercial products, (b) not copy, modify, reverse engineer, decompile, disassemble or otherwise attempt to discover the underlying structure or technology of the Products, or use the Products for the purpose of developing any products or services that would compete with CST products or services, (c) not alter or remove from the Products any trademarks, trade names, logos, patent or copyright notices or markings, (d) use the Products solely in accordance with CST Product Terms of Sale and any applicable documentation, and (e) comply with any license, terms of service or similar agreement with respect to any third party products or services used by Customer in connection with the Products.

Revision 1
#40459

Neurofilament-H (E7Z7G) Rabbit mAb (BSA and Azide Free)

Western Blotting Image 1: Neurofilament-H (E7Z7G) Rabbit mAb (BSA and Azide Free) Expand Image
Western blot analysis of extracts from human cerebellum, mouse brain, and mouse spleen tissue using Neurofilament-H (E7Z7G) Rabbit mAb (upper) or GAPDH (D16H11) XP® Rabbit mAb #5174 (lower). Low expression of Neurofilament-H protein in mouse spleen tissue is consistent with the predicted expression pattern. Data were generated using the standard formulation of this product.
Immunohistochemistry Image 1: Neurofilament-H (E7Z7G) Rabbit mAb (BSA and Azide Free) Expand Image
Immunohistochemical analysis of paraffin-embedded normal mouse midbrain using Neurofilament-H (E7Z7G) Rabbit mAb performed on the Leica® BOND Rx. Data were generated using the standard formulation of this product.
Immunohistochemistry Image 2: Neurofilament-H (E7Z7G) Rabbit mAb (BSA and Azide Free) Expand Image
Immunohistochemical analysis of paraffin-embedded normal mouse pons using Neurofilament-H (E7Z7G) Rabbit mAb performed on the Leica® BOND Rx. Data were generated using the standard formulation of this product.
Immunohistochemistry Image 1: Neurofilament-H (E7Z7G) Rabbit mAb (BSA and Azide Free) Expand Image
Immunohistochemical analysis of paraffin-embedded normal human brain using Neurofilament-H (E7Z7G) Rabbit mAb. Data were generated using the standard formulation of this product.
Immunohistochemistry Image 2: Neurofilament-H (E7Z7G) Rabbit mAb (BSA and Azide Free) Expand Image
Immunohistochemical analysis of paraffin-embedded normal human brain using Neurofilament-H (E7Z7G) Rabbit mAb. Data were generated using the standard formulation of this product.
Immunohistochemistry Image 3: Neurofilament-H (E7Z7G) Rabbit mAb (BSA and Azide Free) Expand Image
Immunohistochemical analysis of paraffin-embedded normal mouse caudoputamen using Neurofilament-H (E7Z7G) Rabbit mAb. Data were generated using the standard formulation of this product.
Immunohistochemistry Image 4: Neurofilament-H (E7Z7G) Rabbit mAb (BSA and Azide Free) Expand Image
Immunohistochemical analysis of paraffin-embedded normal mouse spinal cord using Neurofilament-H (E7Z7G) Rabbit mAb. Data were generated using the standard formulation of this product.
Immunohistochemistry Image 5: Neurofilament-H (E7Z7G) Rabbit mAb (BSA and Azide Free) Expand Image
Immunohistochemical analysis of paraffin-embedded normal human brain (left), normal mouse cerebellum (middle), or normal mouse medulla (right) using Neurofilament-H (E7Z7G) Rabbit mAb (top) or a Neurofilament-H Rabbit pAb (bottom). These two antibodies detect unique, non-overlapping epitopes on Neurofilament-H protein. The similar staining patterns obtained with both antibodies help to confirm the specificity of the staining. Data were generated using the standard formulation of this product.
Immunohistochemistry Image 6: Neurofilament-H (E7Z7G) Rabbit mAb (BSA and Azide Free) Expand Image
Immunohistochemical analysis of paraffin-embedded normal mouse thalamus using Neurofilament-H (E7Z7G) Rabbit mAb (left) compared to concentration-matched Rabbit (DA1E) mAb IgG XP® Isotype Control #3900 (right). Data were generated using the standard formulation of this product.
Immunohistochemistry Image 7: Neurofilament-H (E7Z7G) Rabbit mAb (BSA and Azide Free) Expand Image
Immunohistochemical analysis of paraffin-embedded Kelly cell pellet (left, positive) or SW480 cell pellet (right, negative) using Neurofilament-H (E7Z7G) Rabbit mAb. Data were generated using the standard formulation of this product.
Immunofluorescence Image 1: Neurofilament-H (E7Z7G) Rabbit mAb (BSA and Azide Free) Expand Image
Confocal immunofluorescent analysis of fixed frozen mouse hippocampus labeled with Neurofilament-H (E7Z7G) Rabbit mAb (left, red). Free secondary binding sites were then blocked with Rabbit (DA1E) mAb IgG XP® Isotype Control #3900 prior to co-labeling with GFAP (GA5) Mouse mAb (Alexa Fluor® 488 Conjugate) #3655 (right, green), Iba1/AIF-1 (E4O4W) XP® Rabbit mAb (Alexa Fluor® 647 Conjugate) #78060 (right, yellow), and DAPI #4083 (right, blue). Data were generated using the standard formulation of this product.
Immunofluorescence Image 2: Neurofilament-H (E7Z7G) Rabbit mAb (BSA and Azide Free) Expand Image
Confocal immunofluorescent analysis of fixed frozen mouse pons labeled with Neurofilament-H (E7Z7G) Rabbit mAb (left, red). Free secondary binding sites were then blocked with Rabbit (DA1E) mAb IgG XP® Isotype Control #3900 prior to co-labeling with GFAP (GA5) Mouse mAb (Alexa Fluor® 488 Conjugate) #3655 (right, green), and DAPI #4083 (right, blue). Data were generated using the standard formulation of this product.
Immunofluorescence Image 3: Neurofilament-H (E7Z7G) Rabbit mAb (BSA and Azide Free) Expand Image
Confocal immunofluorescent analysis of fixed frozen mouse retina labeled with Neurofilament-H (E7Z7G) Rabbit mAb (left, red). Free secondary binding sites were then blocked with Rabbit (DA1E) mAb IgG XP® Isotype Control #3900 prior to co-labeling with GFAP (GA5) Mouse mAb (Alexa Fluor® 488 Conjugate) #3655 (right, green), Iba1/AIF-1 (E4O4W) XP® Rabbit mAb (Alexa Fluor® 647 Conjugate) #78060 (right, yellow pseudocolor), and DAPI #4083 (right, blue). Data were generated using the standard formulation of this product.
Immunofluorescence Image 1: Neurofilament-H (E7Z7G) Rabbit mAb (BSA and Azide Free) Expand Image
Confocal immunofluorescent analysis of A2780 cells (left, positive) and UACC-62 cells (right, negative) using Neurofilament-H (E7Z7G) Rabbit mAb (green), DyLight 650 Phalloidin #12956 (red), and DAPI #4083 (blue). Data were generated using the standard formulation of this product.
