REACTIVITY SENSITIVITY MW (kDa) Isotype
All Transfected Only Mouse IgG1

Immunofluorescence (Immunocytochemistry)

Confocal immunofluorescent analysis of Cas9 expression in NPRL2 CRISPR/Cas9 KO plasmid transfected (left) and untransfected (right) 293 cells using Cas9 (7A9-3A3) Mouse mAb (Alexa Fluor® 488 Conjugate) (green). Actin filaments were labeled with DyLight™ 554 Phalloidin #13054 (red). Blue pseudocolor = DRAQ5® #4084 (fluorescent DNA dye). Nprl2 expression was knocked out in the Nprl2-deficient cells by transient transfection of Cas9 and NPRL2-specific guide sequences. Nprl2 -/- cells were kindly provided by Rachel Wolfson, Lynne Chantranupong, and David Sabatini from MIT, Cambridge, MA.

Learn more about how we get our images

Flow Cytometry

Flow cytometric analysis of HEK-293 cells untreated (blue) or transfected with NPRL2 CRISPR/Cas9 KO plasmid (green) using

Cas9 (7A9-3A3) Mouse mAb (Alexa Fluor® 488 Conjugate).

Learn more about how we get our images
Page

Immunofluorescence (Immunocytochemistry)

A. Solutions and Reagents

NOTE: Prepare solutions with reverse osmosis deionized (RODI) or equivalent grade water.

  1. 20X Phosphate Buffered Saline (PBS): (9808) To prepare 1L 1X PBS: add 50 ml 20X PBS to 950 ml dH2O, mix. Adjust pH to 8.0.
  2. Formaldehyde: 16%, methanol free, Polysciences, Inc. (cat# 18814), use fresh and store opened vials at 4°C in dark, dilute in 1X PBS for use.
  3. Blocking Buffer (1X PBS / 5% normal goat serum (#5425) / 0.3% Triton™ X-100): To prepare 10 ml: add 0.5 ml normal goat serum and 0.5 ml 20X PBS to 9.0 ml dH2O, mix. While stirring, add 30 µl Triton™ X-100.
  4. Antibody Dilution Buffer: (1X PBS / 1% BSA / 0.3% Triton™ X-100): To prepare 10 ml, add 30 µl Triton™ X-100 to 10 ml 1X PBS. Mix well then add 0.1 g BSA (#9998), mix.
  5. Prolong® Gold AntiFade Reagent (#9071), Prolong® Gold AntiFade Reagent with DAPI (#8961).

B. Specimen Preparation - Cultured Cell Lines (IF-IC)

NOTE: Cells should be grown, treated, fixed and stained directly in multi-well plates, chamber slides or on coverslips.

  1. Aspirate liquid, then cover cells to a depth of 2–3 mm with 4% formaldehyde diluted in 1X PBS.

    NOTE: Formaldehyde is toxic, use only in a fume hood.

  2. Allow cells to fix for 15 min at room temperature.
  3. Aspirate fixative, rinse three times in 1X PBS for 5 min each.
  4. Proceed with Immunostaining (Section C).

C. Immunostaining

NOTE: All subsequent incubations should be carried out at room temperature unless otherwise noted in a humid light-tight box or covered dish/plate to prevent drying and fluorochrome fading.

  1. Block specimen in Blocking Buffer for 60 min.
  2. While blocking, prepare primary antibody by diluting as indicated on datasheet in Antibody Dilution Buffer.
  3. Aspirate blocking solution, apply diluted primary antibody.
  4. Incubate overnight at 4°C.
  5. Rinse three times in 1X PBS for 5 min each.
  6. Coverslip slides with Prolong® Gold Antifade Reagent (#9071) or Prolong® Gold Antifade Reagent with DAPI (#8961).
  7. For best results, allow mountant to cure overnight at room temperature. For long-term storage, store slides flat at 4°C protected from light.

posted November 2006

revised November 2013

Protocol Id: 182
Page

Flow Cytometry General Protocol

If using whole blood, please follow the Flow Cytometry Whole Blood Protocol.

A. Solutions and Reagents

NOTE: Prepare solutions with reverse osmosis deionized (RODI) or equivalent grade water.

  1. 20X Phosphate Buffered Saline (PBS): (#9808) To prepare 1 L 1X PBS: add 50 ml 20X PBS to 950 ml dH2O, mix.
  2. 16% Formaldehyde (methanol free).
  3. 100% methanol.
  4. Incubation Buffer: Dissolve 0.5 g Bovine Serum Albumin (BSA) (#9998) in 100 ml 1X PBS. Store at 4°C.

B. Fixation

  1. Collect cells by centrifugation and aspirate supernatant.
  2. Resuspend cells in 0.5–1 ml 1X PBS. Add formaldehyde to obtain a final concentration of 1%.
  3. Fix for 10 min on ice.
  4. For extracellular staining with antibodies that do not require permeabilization, proceed to immunostaining (Section D) or store cells in PBS with 0.1% sodium azide at 4°C; for intracellular staining, proceed to permeabilization (Section C).

C. Permeabilization

NOTE: This step is critical for many CST antibodies.

  1. Remove fix prior to permeabilization by centrifugation and resuspend in 100% methanol.
  2. Incubate 30 min on ice.
  3. Proceed with immunostaining (Section D) or store cells at -20°C in 100% methanol.

D. Immunostaining

NOTE: Account for isotype matched controls for monoclonal antibodies or species matched IgG for polyclonal antibodies. Count cells using a hemocytometer or alternative method.

  1. Aliquot 0.5–1 x 106 cells into each assay tube (by volume).
  2. Add 2–3 ml incubation buffer to each tube and wash by centrifugation. Repeat.
  3. Resuspend cells in 100 µl of diluted primary antibody (prepared in incubation buffer at the recommended dilution).
  4. Incubate for 1 hr at room temperature.
  5. Wash by centrifugation in 2–3 ml incubation buffer.
  6. Resuspend cells in 0.5 ml PBS and analyze on flow cytometer; alternatively, for DNA staining, proceed to optional DNA stain (Section E).

E. Optional DNA Dye

  1. Resuspend cells in 0.5 ml of DNA dye (e.g. Propidium Iodide (PI)/RNase Staining Solution #4087).
  2. Incubate for at least 30 min at room temperature.
  3. Analyze cells in DNA staining solution on flow cytometer.

posted October 2015

Flow Cytometry Whole Blood Protocol

If using cell lines, please follow the Flow Cytometry General Protocol.

A. Solutions and Reagents

NOTE: Prepare solutions with reverse osmosis deionized (RODI) or equivalent grade water.

  1. 20X Phosphate Buffered Saline (PBS): (#9808) To prepare 1 L 1X PBS: add 50 ml 20X PBS to 950 ml dH2O, mix.
  2. 16% Formaldehyde (methanol free).
  3. Triton™ X-100: To prepare 50 ml of 0.1% Triton™ X-100 add 50 μl Triton™ X-100 to 50 ml 1 X PBS and mix well.
  4. 50% methanol.
  5. Incubation Buffer: Dissolve 0.5 g Bovine Serum Albumin (BSA) (#9998) in 100 ml 1X PBS. Store at 4°C.

B. Preparation of Whole Blood (fixation, lysis, and permeabilization) for Immunostaining

  1. Aliquot 100 μl fresh whole blood per assay tube.
  2. OPTIONAL: Place tubes in rack in 37°C water bath for short-term treatments with ligands, inhibitors, drugs, etc.
  3. Add 65 μl of 10% formaldehyde to each tube.
  4. Vortex briefly and let stand for 15 min at room temperature.
  5. Add 1 ml of 0.1% Triton™ X-100 to each tube.
  6. Vortex and let stand for 30 min at room temperature.
  7. Add 1 ml incubation buffer.
  8. Pellet cells by centrifugation and aspirate supernatant.
  9. Repeat steps 7 and 8.
  10. Resuspend cells in ice-cold 50% methanol in PBS (store methanol solution at -20°C until use).
  11. Incubate at least 10 min on ice.
  12. Proceed with staining or store cells at -20°C in 50% methanol.

C. Staining Using Conjugated Primary Antibodies

NOTE: Account for isotype-matched controls for monoclonal antibodies or species matched IgG for polyclonal antibodies.

  1. Add 2–3 ml incubation buffer to each tube and rinse by centrifugation. Repeat.
  2. Add primary antibodies diluted as recommended on datasheet or product webpage in incubation buffer.
  3. Incubate for 1 hr at room temperature.
  4. Wash by centrifugation in 2–3 ml incubation buffer.
  5. Resuspend cells in 0.5 ml PBS and analyze on flow cytometer.

Reference: Chow S, Hedley D, Grom P, Magari R, Jacobberger JW, Shankey TV (2005) Whole blood fixation and permeabilization protocol with red blood cell lysis for flow cytometry of intracellular phosphorylated epitopes in leukocyte subpopulations. Cytometry A 67(1), 4–17.

posted November 2008

revised September 2013

Protocol Id: 784

Product Usage Information

Application Dilutions
Immunofluorescence (Immunocytochemistry) 1:100
Flow Cytometry 1:50

Storage: Supplied in PBS (pH 7.2), less than 0.1% sodium azide and 2 mg/ml BSA. Store at 4°C. Do not aliquot the antibody. Protect from light. Do not freeze.

Specificity / Sensitivity

Cas9 (7A9-3A3) Mouse mAb (Alexa Fluor® 488 Conjugate) recognizes transfected levels of total Cas9 protein.


Species Reactivity: All Species Expected

Source / Purification

Monoclonal antibody is produced by immunizing animals with recombinant protein specific to the amino terminus of Cas9 from Streptococcus pyogene.

Product Description

This Cell Signaling Technology antibody is conjugated to Alexa Fluor® 488 fluorescent dye and tested in-house for direct flow cytometric analysis in human cells. This antibody is expected to exhibit the same species cross-reactivity as the unconjugated Cas9 (7A9-3A3) Mouse mAb #14697.


The CRISPR associated protein 9 (Cas9) is an RNA-guided DNA nuclease and part of the Streptococcus pyogenes CRISPR antiviral immunity system that provides adaptive immunity against extra chromosomal genetic material (1). The CRISPR antiviral mechanism of action involves three steps: (i), acquisition of foreign DNA by host bacterium; (ii), synthesis and maturation of CRISPR RNA (crRNA) followed by the formation of RNA-Cas nuclease protein complexes; and (iii), target interference through recognition of foreign DNA by the complex and its cleavage by Cas nuclease activity (2). The type II CRISPR/Cas antiviral immunity system provides a powerful tool for precise genome editing and has potential for specific gene regulation and therapeutic applications (3). The Cas9 protein and a guide RNA consisting of a fusion between a crRNA and a trans-activating crRNA (tracrRNA) must be introduced or expressed in a cell. A 20-nucleotide sequence at the 5' end of the guide RNA directs Cas9 to a specific DNA target site. As a result, Cas9 can be "programmed" to cut various DNA sites both in vitro and in cells and organisms. CRISPR/Cas9 genome editing tools have been used in many organisms, including mouse and human cells (4,5). Research studies demonstrate that CRISPR can be used to generate mutant alleles or reporter genes in rodents and primate embryonic stem cells (6-8).


1.  Horvath, P. and Barrangou, R. (2010) Science 327, 167-70.

2.  Wiedenheft, B. et al. (2012) Nature 482, 331-8.

3.  Singh, P. et al. (2015) Genetics 199, 1-15.

4.  Cong, L. et al. (2013) Science 339, 819-23.

5.  Mali, P. et al. (2013) Science 339, 823-6.

6.  Li, D. et al. (2013) Nat Biotechnol 31, 681-3.

7.  Shen, B. et al. (2013) Cell Res 23, 720-3.

8.  Niu, Y. et al. (2014) Cell 156, 836-43.


Entrez-Gene Id 901176
Swiss-Prot Acc. Q99ZW2
