REACTIVITY SENSITIVITY MW (kDa) Isotype
All Transfected Only Mouse IgG1

Flow Cytometry

Flow cytometric analysis of HEK-293 cells untreated (blue) or transfected with NPRL2 CRISPR/Cas9 KO plasmid (green) using Cas9 (7A9-3A3) Mouse mAb (PE Conjugate).

Learn more about how we get our images
Page

Flow Cytometry General Protocol

If using whole blood, please follow the Flow Cytometry Whole Blood Protocol.

A. Solutions and Reagents

NOTE: Prepare solutions with reverse osmosis deionized (RODI) or equivalent grade water.

  1. 20X Phosphate Buffered Saline (PBS): (#9808) To prepare 1 L 1X PBS: add 50 ml 20X PBS to 950 ml dH2O, mix.
  2. 16% Formaldehyde (methanol free).
  3. 100% methanol.
  4. Incubation Buffer: Dissolve 0.5 g Bovine Serum Albumin (BSA) (#9998) in 100 ml 1X PBS. Store at 4°C.

B. Fixation

  1. Collect cells by centrifugation and aspirate supernatant.
  2. Resuspend cells in 0.5–1 ml 1X PBS. Add formaldehyde to obtain a final concentration of 1%.
  3. Fix for 10 min on ice.
  4. For extracellular staining with antibodies that do not require permeabilization, proceed to immunostaining (Section D) or store cells in PBS with 0.1% sodium azide at 4°C; for intracellular staining, proceed to permeabilization (Section C).

C. Permeabilization

NOTE: This step is critical for many CST antibodies.

  1. Remove fix prior to permeabilization by centrifugation and resuspend in 100% methanol.
  2. Incubate 30 min on ice.
  3. Proceed with immunostaining (Section D) or store cells at -20°C in 100% methanol.

D. Immunostaining

NOTE: Account for isotype matched controls for monoclonal antibodies or species matched IgG for polyclonal antibodies. Count cells using a hemocytometer or alternative method.

  1. Aliquot 0.5–1 x 106 cells into each assay tube (by volume).
  2. Add 2–3 ml incubation buffer to each tube and wash by centrifugation. Repeat.
  3. Resuspend cells in 100 µl of diluted primary antibody (prepared in incubation buffer at the recommended dilution).
  4. Incubate for 1 hr at room temperature.
  5. Wash by centrifugation in 2–3 ml incubation buffer.
  6. Resuspend cells in 0.5 ml PBS and analyze on flow cytometer; alternatively, for DNA staining, proceed to optional DNA stain (Section E).

E. Optional DNA Dye

  1. Resuspend cells in 0.5 ml of DNA dye (e.g. Propidium Iodide (PI)/RNase Staining Solution #4087).
  2. Incubate for at least 30 min at room temperature.
  3. Analyze cells in DNA staining solution on flow cytometer.

posted October 2015

Flow Cytometry Whole Blood Protocol

If using cell lines, please follow the Flow Cytometry General Protocol.

A. Solutions and Reagents

NOTE: Prepare solutions with reverse osmosis deionized (RODI) or equivalent grade water.

  1. 20X Phosphate Buffered Saline (PBS): (#9808) To prepare 1 L 1X PBS: add 50 ml 20X PBS to 950 ml dH2O, mix.
  2. 16% Formaldehyde (methanol free).
  3. Triton™ X-100: To prepare 50 ml of 0.1% Triton™ X-100 add 50 μl Triton™ X-100 to 50 ml 1 X PBS and mix well.
  4. 50% methanol.
  5. Incubation Buffer: Dissolve 0.5 g Bovine Serum Albumin (BSA) (#9998) in 100 ml 1X PBS. Store at 4°C.

B. Preparation of Whole Blood (fixation, lysis, and permeabilization) for Immunostaining

  1. Aliquot 100 μl fresh whole blood per assay tube.
  2. OPTIONAL: Place tubes in rack in 37°C water bath for short-term treatments with ligands, inhibitors, drugs, etc.
  3. Add 65 μl of 10% formaldehyde to each tube.
  4. Vortex briefly and let stand for 15 min at room temperature.
  5. Add 1 ml of 0.1% Triton™ X-100 to each tube.
  6. Vortex and let stand for 30 min at room temperature.
  7. Add 1 ml incubation buffer.
  8. Pellet cells by centrifugation and aspirate supernatant.
  9. Repeat steps 7 and 8.
  10. Resuspend cells in ice-cold 50% methanol in PBS (store methanol solution at -20°C until use).
  11. Incubate at least 10 min on ice.
  12. Proceed with staining or store cells at -20°C in 50% methanol.

C. Staining Using Conjugated Primary Antibodies

NOTE: Account for isotype-matched controls for monoclonal antibodies or species matched IgG for polyclonal antibodies.

  1. Add 2–3 ml incubation buffer to each tube and rinse by centrifugation. Repeat.
  2. Add primary antibodies diluted as recommended on datasheet or product webpage in incubation buffer.
  3. Incubate for 1 hr at room temperature.
  4. Wash by centrifugation in 2–3 ml incubation buffer.
  5. Resuspend cells in 0.5 ml PBS and analyze on flow cytometer.

Reference: Chow S, Hedley D, Grom P, Magari R, Jacobberger JW, Shankey TV (2005) Whole blood fixation and permeabilization protocol with red blood cell lysis for flow cytometry of intracellular phosphorylated epitopes in leukocyte subpopulations. Cytometry A 67(1), 4–17.

posted November 2008

revised September 2013

Protocol Id: 784

Product Usage Information

Application Dilutions
Flow Cytometry 1:50

Storage: Supplied in PBS (pH 7.2), less than 0.1% sodium azide and 2 mg/ml BSA. Store at 4°C. Do not aliquot the antibodies. Protect from light. Do not freeze.

Specificity / Sensitivity

Cas9 (7A9-3A3) Mouse mAb (PE Conjugate) recognizes transfected levels of total Cas9 protein.


Species Reactivity: All Species Expected

Source / Purification

Monoclonal antibody is produced by immunizing animals with recombinant protein specific to the amino terminus of Cas9 from Streptococcus pyogene.

Product Description

This Cell Signaling Technology antibody is conjugated to phycoerythrin (PE) and tested in-house for direct flow cytometry analysis in human cells. This antibody is expected to exhibit the same species cross-reactivity as the unconjugated Cas9 (7A9-3A3) Mouse mAb #14697.


The CRISPR associated protein 9 (Cas9) is an RNA-guided DNA nuclease and part of the Streptococcus pyogenes CRISPR antiviral immunity system that provides adaptive immunity against extra chromosomal genetic material (1). The CRISPR antiviral mechanism of action involves three steps: (i), acquisition of foreign DNA by host bacterium; (ii), synthesis and maturation of CRISPR RNA (crRNA) followed by the formation of RNA-Cas nuclease protein complexes; and (iii), target interference through recognition of foreign DNA by the complex and its cleavage by Cas nuclease activity (2). The type II CRISPR/Cas antiviral immunity system provides a powerful tool for precise genome editing and has potential for specific gene regulation and therapeutic applications (3). The Cas9 protein and a guide RNA consisting of a fusion between a crRNA and a trans-activating crRNA (tracrRNA) must be introduced or expressed in a cell. A 20-nucleotide sequence at the 5' end of the guide RNA directs Cas9 to a specific DNA target site. As a result, Cas9 can be "programmed" to cut various DNA sites both in vitro and in cells and organisms. CRISPR/Cas9 genome editing tools have been used in many organisms, including mouse and human cells (4,5). Research studies demonstrate that CRISPR can be used to generate mutant alleles or reporter genes in rodents and primate embryonic stem cells (6-8).


1.  Horvath, P. and Barrangou, R. (2010) Science 327, 167-70.

2.  Wiedenheft, B. et al. (2012) Nature 482, 331-8.

3.  Singh, P. et al. (2015) Genetics 199, 1-15.

4.  Cong, L. et al. (2013) Science 339, 819-23.

5.  Mali, P. et al. (2013) Science 339, 823-6.

6.  Li, D. et al. (2013) Nat Biotechnol 31, 681-3.

7.  Shen, B. et al. (2013) Cell Res 23, 720-3.

8.  Niu, Y. et al. (2014) Cell 156, 836-43.


Entrez-Gene Id 901176
Swiss-Prot Acc. Q99ZW2
