AFP (C3) Mouse mAb
Primary Antibodies
Monoclonal Antibody

AFP (C3) Mouse mAb #39971

Reviews ()
Citations (0)
Filter:
  1. IHC
Immunohistochemistry Image 1: AFP (C3) Mouse mAb
Immunohistochemical analysis of paraffin-embedded human hepatocellular carcinoma using AFP (C3) Mouse mAb performed on the Leica® BOND Rx.
Immunohistochemistry Image 2: AFP (C3) Mouse mAb
Immunohistochemical analysis of paraffin-embedded human hepatocellular carcinoma using AFP (C3) Mouse mAb performed on the Leica® BOND Rx.
Immunohistochemistry Image 1: AFP (C3) Mouse mAb
Immunohistochemical analysis of paraffin-embedded human hepatocellular carcinoma (left-top), breast carcinoma (middle-top), colon carcinoma (right-top), normal liver (left-bottom), normal lymph node (middle-bottom), and normal pancreas (right-bottom) using AFP (C3) Mouse mAb.
Immunohistochemistry Image 2: AFP (C3) Mouse mAb
Immunohistochemical analysis of paraffin-embedded human hepatocellular carcinoma using AFP (C3) Mouse mAb (left) compared to concentration-matched Mouse (E5Y6Q) mAb IgG2a Isotype Control #61656 (right).
Immunohistochemistry Image 3: AFP (C3) Mouse mAb
Immunohistochemical analysis of paraffin-embedded Hep G2 cell pellet (left, positive) or HLE cell pellet (right, negative) using AFP (C3) Mouse mAb.
To Purchase # 39971
Cat. # Size Qty. Price
39971S
100 µl $ 285

Supporting Data

REACTIVITY H
SENSITIVITY Endogenous
MW (kDa)
Source/Isotype Mouse IgG2a

Application Key:

  • WB-Western Blot
  • IP-Immunoprecipitation
  • IHC-Immunohistochemistry
  • ChIP-Chromatin Immunoprecipitation
  • IF-Immunofluorescence
  • F-Flow Cytometry
  • E-P-ELISA-Peptide

Species Cross-Reactivity Key:

  • H-Human
  • M-Mouse
  • R-Rat
  • Hm-Hamster
  • Mk-Monkey
  • Vir-Virus
  • Mi-Mink
  • C-Chicken
  • Dm-D. melanogaster
  • X-Xenopus
  • Z-Zebrafish
  • B-Bovine
  • Dg-Dog
  • Pg-Pig
  • Sc-S. cerevisiae
  • Ce-C. elegans
  • Hr-Horse
  • All-All Species Expected

Product Usage Information

Application Dilution
IHC-Leica® Bond™ 1:50 - 1:200
Immunohistochemistry (Paraffin) 1:100 - 1:400

Storage

Supplied as liquid tissue culture supernatant containing sodium azide as a preservative. Stable for 12 months when stored at 4°C. Do not aliquot the antibody.

Protocol

PRINT

View >Collapse >

Immunohistochemistry (Leica®BOND™)

NOTE: Please see product datasheet or product webpage for appropriate antibody dilution^.

  Step Reagents Time/Temperature
1 Dewax BOND™ Dewax Solution, 100% Alcohol, BOND™ Wash Solution Pre-programmed Leica® BOND™
2 Antigen Retrieval  BOND™ Epitope Retrieval ER2 Solution 20 min., 100˚C | Protocol: HIER 20 min with ER2
3 Peroxide Block Polymer Refine Detection Kit Peroxide Block* 5 min.
  WASH BOND™ Wash Solution  3x 0:00 min.
4 Protein Block (optional) #5425 NGS or #15019 Animal-Free Blocking Solution   20 min.
5 Primary Antibody^ Dilute in #8112 SignalStain® Antibody Diluent 30 min.
  WASH BOND™ Wash Solution  3x 2:00 min.
6 Post Primary Mouse Linker Polymer Refine Detection Kit Post Primary*  10 min.
  WASH BOND™ Wash Solution  3x 2:00 min.
7 Secondary Detection Polymer Refine Detection Kit Polymer*  10 min.
  WASH BOND™ Wash Solution/Deionized Water Custom (see below)
8a Visualization Polymer Refine Detection Kit Mixed DAB Refine*  0:00 min.
8b Visualization Polymer Refine Detection Kit Mixed DAB Refine*  10 min.
  WASH Deionized Water 3x 0:00 min.
9 Counterstain Polymer Refine Detection Kit Hematoxylin*  5 min.
  WASH Deionized Water 0:00 min.
  WASH BOND™ Wash Solution  0:00 min.
  WASH Deionized Water 0:00 min.
10 Dehydration (Offline):
  Incubate sections in 95% ethanol two times for 10 seconds each.
  Repeat in 100% ethanol, incubating sections two times for 10 seconds each.
  Repeat in xylene, incubating sections two times for 10 seconds each.
11 Mount sections with coverslips and #14177 SignalStain® Mounting Medium

  Optional Custom wash:  BOND™ Wash Solution 2:00
    BOND™ Wash Solution Dispenser Type: OPEN 0:00
    BOND™ Wash Solution 2:00
    BOND™ Wash Solution Dispenser Type: OPEN 0:00
    BOND™ Wash Solution 0:00
    Deionized Water 0:00

*Reagent included in BOND™ Polymer Refine Detection Kit (Catalog No: DS9800)

LEICA® is a registered trademark of Leica Microsystems IR GmbH.

BOND™ is a trademark of Leica Biosystems Melbourne Pty. Ltd. No affiliation or sponsorship between CST and Leica Microsystems IR GmbH or Leica Biosystems Melbourne Pty. Ltd is implied.

posted August 2018

revised September 2018

Protocol Id: 1445

Immunohistochemistry (Paraffin)

A. Solutions and Reagents

NOTE: Prepare solutions with reverse osmosis deionized (RODI) or equivalent grade water.

  1. Xylene.
  2. Ethanol, anhydrous denatured, histological grade (100% and 95%).
  3. Deionized water (dH2O).
  4. Hematoxylin (optional).
  5. Wash Buffer:
    1. 1X Tris Buffered Saline with Tween® 20 (TBST): To prepare 1L 1X TBST add 100 ml 10X Tris Buffered Saline with Tween ® 20 (#9997) to 900 ml dH 2O, mix.
  6. SignalStain® Antibody Diluent (#8112).
  7. 1X Citrate Unmasking Solution: To prepare 250 mL of 1X citrate unmasking solution, dilute 25 ml of SignalStain® Citrate Unmasking Solution (10X) (#14746) with 225 mL of dH2O.
  8. 3% Hydrogen Peroxide: To prepare 100 ml, add 10 ml 30% H 2O2 to 90 ml dH2O.
  9. Blocking Solution: TBST/5% Normal Goat Serum or 1X Animal-Free Blocking Solution.
    1. TBST/5% Normal Goat Serum: to 5 ml 1X TBST, add 250 µl Normal Goat Serum (#5425).
    2. 1X Animal-Free Blocking Solution: to 4 mL of dH2O add 1 ml of Animal-Free Blocking Solution (5X) (#15019).
  10. Detection System: SignalStain® Boost IHC Detection Reagents (HRP, Mouse #8125).
  11. Substrate: SignalStain® DAB Substrate Kit (#8059).
  12. Hematoxylin: Hematoxylin (#14166).
  13. Mounting Medium: SignalStain® Mounting Medium (#14177).

B. Deparaffinization/Rehydration

NOTE: Do not allow slides to dry at any time during this procedure.

  1. Deparaffinize/hydrate sections:
    1. Incubate sections in three washes of xylene for 5 min each.
    2. Incubate sections in two washes of 100% ethanol for 10 min each.
    3. Incubate sections in two washes of 95% ethanol for 10 min each.
  2. Wash sections two times in dH2O for 5 min each.

C. Antigen Unmasking

For Citrate: Heat slides in a microwave submersed in 1X citrate unmasking solution until boiling is initiated; follow with 10 min at a sub-boiling temperature (95°-98°C). Cool slides on bench top for 30 min.

D. Staining

  1. Wash sections in dH2O three times for 5 min each.
  2. Incubate sections in 3% hydrogen peroxide for 10 min.
  3. Wash sections in dH2O two times for 5 min each.
  4. Wash sections in wash buffer for 5 min.
  5. Block each section with 100–400 µl of preferred blocking solution for 1 hr at room temperature.
  6. Remove blocking solution and add 100–400 µl primary antibody diluted in SignalStain® Antibody Diluent (#8112) to each section. Incubate overnight at 4°C.
  7. Equilibrate SignalStain® Boost Detection Reagent (HRP, Mouse #8125) to room temperature.
  8. Remove antibody solution and wash sections with wash buffer three times for 5 min each.
  9. Cover section with 1–3 drops SignalStain® Boost Detection Reagent (HRP, Mouse #8125) as needed. Incubate in a humidified chamber for 30 min at room temperature.
  10. Wash sections three times with wash buffer for 5 min each.
  11. Add 1 drop (30 µl) SignalStain® DAB Chromogen Concentrate to 1 ml SignalStain® DAB Diluent and mix well before use.
  12. Apply 100–400 µl SignalStain® DAB to each section and monitor closely. 5–10 min generally provides an acceptable staining intensity.
  13. Immerse slides in dH2O.
  14. If desired, counterstain sections with hematoxylin (#14166).
  15. Wash sections in dH2O two times for 5 min each.
  16. Dehydrate sections:
    1. Incubate sections in 95% ethanol two times for 10 sec each.
    2. Repeat in 100% ethanol, incubating sections two times for 10 sec each.
    3. Repeat in xylene, incubating sections two times for 10 sec each.
  17. Mount sections with coverslips and mounting medium (#14177).
DETECTION REAGENT/SUBSTRATE COMPATIBILITY
RECOMMENDED
DETECTION REAGENTS
SignalStain® Boost IHC Detection Reagent (HRP, Mouse) #8125 SignalStain® Boost IHC Detection Reagent (AP, Mouse) #31926
COMPATIBLE
CHROMOGEN
SignalStain® DAB Substrate Kit #8059 SignalStain® Vibrant Red Alkaline Phosphatase Substrate Kit #76713
SignalStain® Vivid Purple Peroxidase Substrate Kit #96632

NOTE: Use of detection reagents other than those specified in this protocol may require further optimization of the primary antibody to account for the different sensitivities of the detection reagents.

posted February 2010

revised April 2020

Protocol Id: 1991

Specificity / Sensitivity

AFP (C3) Mouse mAb recognizes endogenous levels of alpha-fetoprotein (AFP).

Species Reactivity:

Human

Source / Purification

Monoclonal antibody is produced by immunizing animals with serum of a hepatoma patient that has affinity isolated human alpha-fetoprotein (AFP).

Background

Alpha-fetoprotein (AFP) is a 65 kDa glycoprotein found in the mammalian fetal liver, yolk sac, and GI tract. While AFP expression in adult cells is low, it is aberrantly expressed in adult liver cancer cells (1,2). The tumor suppressor gene p53 and β-catenin are both involved in the regulation of AFP expression. In normal adult cells, p53 binds to the repressor region of the AFP gene, thereby blocking transcription. Mutations in both p53 and β-catenin are associated with aberrant expression of AFP. Research studies have shown that elevated serum AFP levels are predictive of hepatocellular carcinoma (3).
  1. Meier, V. et al. (2006) Comp Hepatol 5, 2.
  2. Warnes, T.W. and Smith, A. (1987) Baillieres Clin Gastroenterol 1, 63-89.
  3. Peng, S.Y. et al. (2004) Int J Cancer 112, 44-50.
