76799
HER2/ErbB2 (CB11) Mouse mAb
Primary Antibodies
Monoclonal Antibody

HER2/ErbB2 (CB11) Mouse mAb #76799

Reviews ()
Citations (0)
Filter:
  1. IHC
Immunohistochemistry Image 1: HER2/ErbB2 (CB11) Mouse mAb
Immunohistochemical analysis of paraffin-embedded human ductal breast carcinoma using HER2/ErbB2 (CB11) Mouse mAb performed on the Leica® BOND Rx.
Immunohistochemistry Image 2: HER2/ErbB2 (CB11) Mouse mAb
Immunohistochemical analysis of paraffin-embedded human urothelial carcinoma using HER2/ErbB2 (CB11) Mouse mAb performed on the Leica® BOND Rx.
Immunohistochemistry Image 3: HER2/ErbB2 (CB11) Mouse mAb
Immunohistochemical analysis of paraffin-embedded human ovarian clear cell carcinoma using HER2/ErbB2 (CB11) Mouse mAb performed on the Leica® BOND Rx.
Immunohistochemistry Image 4: HER2/ErbB2 (CB11) Mouse mAb
Immunohistochemical analysis of paraffin-embedded human esophageal carcinoma using HER2/ErbB2 (CB11) Mouse mAb performed on the Leica® BOND Rx.
Immunohistochemistry Image 1: HER2/ErbB2 (CB11) Mouse mAb
Immunohistochemical analysis of paraffin-embedded human colon carcinoma using HER2/ErbB2 (CB11) Mouse mAb.
Immunohistochemistry Image 2: HER2/ErbB2 (CB11) Mouse mAb
Immunohistochemical analysis of paraffin-embedded human urothelial carcinoma using HER2/ErbB2 (CB11) Mouse mAb (left) compared to concentration-matched Mouse (G3A1) mAb IgG1 Isotype Control #5415 (right).
Immunohistochemistry Image 3: HER2/ErbB2 (CB11) Mouse mAb
Immunohistochemical analysis of paraffin-embedded SK-BR-3 cell pellet (left, positive) or MDA-MB-231 cell pellet (right, negative) using HER2/ErbB2 (CB11) Mouse mAb.
To Purchase # 76799
Cat. # Size Qty. Price
76799S
100 µl $ 285

Supporting Data

REACTIVITY H
SENSITIVITY Endogenous
MW (kDa)
Source/Isotype Mouse IgG1

Application Key:

  • WB-Western Blot
  • IP-Immunoprecipitation
  • IHC-Immunohistochemistry
  • ChIP-Chromatin Immunoprecipitation
  • IF-Immunofluorescence
  • F-Flow Cytometry
  • E-P-ELISA-Peptide

Species Cross-Reactivity Key:

  • H-Human
  • M-Mouse
  • R-Rat
  • Hm-Hamster
  • Mk-Monkey
  • Vir-Virus
  • Mi-Mink
  • C-Chicken
  • Dm-D. melanogaster
  • X-Xenopus
  • Z-Zebrafish
  • B-Bovine
  • Dg-Dog
  • Pg-Pig
  • Sc-S. cerevisiae
  • Ce-C. elegans
  • Hr-Horse
  • All-All Species Expected

Product Usage Information

Application Dilution
IHC-Leica® Bond™ 1:200 - 1:800
Immunohistochemistry (Paraffin) 1:50 - 1:200

Storage

Supplied as liquid tissue culture supernatant containing sodium azide as a preservative. Stable for 12 months when stored at 4°C. Do not aliquot the antibody.

Protocol

PRINT

View >Collapse >

Immunohistochemistry (Leica®BOND™)

NOTE: Please see product datasheet or product webpage for appropriate antibody dilution^.

  Step Reagents Time/Temperature
1 Dewax BOND™ Dewax Solution, 100% Alcohol, BOND™ Wash Solution Pre-programmed Leica® BOND™
2 Antigen Retrieval  BOND™ Epitope Retrieval ER2 Solution 20 min., 100˚C | Protocol: HIER 20 min with ER2
3 Peroxide Block Refine Detection Kit Peroxide Block* 5 min.
  WASH BOND™ Wash Solution  3x 0:00 min.
4 Protein Block (optional) #5425 NGS or #15019 Animal-Free Blocking Solution   20 min.
5 Primary Antibody^ Dilute in #8112 SignalStain® Antibody Diluent 60 min.
  WASH BOND™ Wash Solution  3x 2:00 min.
6 Post Primary Mouse Linker Refine Detection Kit Post Primary*  10 min.
  WASH BOND™ Wash Solution  3x 2:00 min.
7 Secondary Detection Refine Detection Kit Polymer*  10 min.
  WASH BOND™ Wash Solution/Deionized Water Custom (see below)
8a Visualization Refine Detection Kit Mixed DAB Refine*  0:00 min.
8b Visualization Refine Detection Kit Mixed DAB Refine*  10 min.
  WASH Deionized Water 3x 0:00 min.
9 Counterstain Refine Detection Kit Hematoxylin*  5 min.
  WASH Deionized Water 0:00 min.
  WASH BOND™ Wash Solution  0:00 min.
  WASH Deionized Water 0:00 min.
10 Dehydration (Offline):
  Incubate sections in 95% ethanol two times for 10 seconds each.
  Repeat in 100% ethanol, incubating sections two times for 10 seconds each.
  Repeat in xylene, incubating sections two times for 10 seconds each.
11 Mount sections with coverslips and #14177 SignalStain® Mounting Medium

  Optional Custom wash:  BOND™ Wash Solution 2:00
    BOND™ Wash Solution Dispenser Type: OPEN 0:00
    BOND™ Wash Solution 2:00
    BOND™ Wash Solution Dispenser Type: OPEN 0:00
    BOND™ Wash Solution 0:00
    Deionized Water 0:00

*Reagent included in BOND™ Polymer Refine Detection Kit (Catalog No: DS9800)

LEICA® is a registered trademark of Leica Microsystems IR GmbH.

BOND™ is a trademark of Leica Biosystems Melbourne Pty. Ltd. No affiliation or sponsorship between CST and Leica Microsystems IR GmbH or Leica Biosystems Melbourne Pty. Ltd is implied.

posted August 2018

revised September 2018

Protocol Id: 1484

Immunohistochemistry (Paraffin)

A. Solutions and Reagents

NOTE: Prepare solutions with reverse osmosis deionized (RODI) or equivalent grade water.

  1. Xylene.
  2. Ethanol, anhydrous denatured, histological grade (100% and 95%).
  3. Deionized water (dH2O).
  4. Hematoxylin (optional).
  5. Wash Buffer:
    1. 1X Tris Buffered Saline with Tween® 20 (TBST): To prepare 1L 1X TBST add 100 ml 10X Tris Buffered Saline with Tween ® 20 (#9997) to 900 ml dH 2O, mix.
  6. SignalStain® Antibody Diluent (#8112).
  7. 1X EDTA Unmasking Solution: To prepare 250 mL of 1X EDTA unmasking solution, dilute 25 ml of SignalStain® EDTA Unmasking Solution (10X) (#14747) with 225 mL of dH 2O.
  8. 3% Hydrogen Peroxide: To prepare 100 ml, add 10 ml 30% H 2O2 to 90 ml dH2O.
  9. Blocking Solution: TBST/5% Normal Goat Serum or 1X Animal-Free Blocking Solution.
    1. TBST/5% Normal Goat Serum: to 5 ml 1X TBST, add 250 µl Normal Goat Serum (#5425).
    2. 1X Animal-Free Blocking Solution: to 4 mL of dH2O, add 1 ml of Animal-Free Blocking Solution (5X) (#15019).
  10. Detection System: SignalStain® Boost IHC Detection Reagents (HRP, Mouse #8125).
  11. Substrate: SignalStain® DAB Substrate Kit (#8059).
  12. Hematoxylin: Hematoxylin (#14166).
  13. Mounting Medium: SignalStain® Mounting Medium (#14177).

B. Deparaffinization/Rehydration

NOTE: Do not allow slides to dry at any time during this procedure.

  1. Deparaffinize/hydrate sections:
    1. Incubate sections in three washes of xylene for 5 min each.
    2. Incubate sections in two washes of 100% ethanol for 10 min each.
    3. Incubate sections in two washes of 95% ethanol for 10 min each.
  2. Wash sections two times in dH2O for 5 min each.

C. Antigen Unmasking

For EDTA: Heat slides in a microwave submersed in 1X EDTA unmasking solution until boiling is initiated; follow with 15 min at a sub-boiling temperature (95°-98°C). No cooling is necessary.

D. Staining

  1. Wash sections in dH2O three times for 5 min each.
  2. Incubate sections in 3% hydrogen peroxide for 10 min.
  3. Wash sections in dH2O two times for 5 min each.
  4. Wash sections in wash buffer for 5 min.
  5. Block each section with 100–400 µl of preferred blocking solution for 1 hr at room temperature.
  6. Remove blocking solution and add 100–400 µl primary antibody diluted in SignalStain ® Antibody Diluent (#8112) to each section. Incubate overnight at 4°C.
  7. Equilibrate SignalStain® Boost Detection Reagent (HRP, Mouse #8125) to room temperature.
  8. Remove antibody solution and wash sections with wash buffer three times for 5 min each.
  9. Cover section with 1–3 drops SignalStain® Boost Detection Reagent (HRP, Mouse #8125) as needed. Incubate in a humidified chamber for 30 min at room temperature.
  10. Wash sections three times with wash buffer for 5 min each.
  11. Add 1 drop (30 µl) SignalStain® DAB Chromogen Concentrate to 1 ml SignalStain ® DAB Diluent and mix well before use.
  12. Apply 100–400 µl SignalStain® DAB to each section and monitor closely. 5–10 min generally provides an acceptable staining intensity.
  13. Immerse slides in dH2O.
  14. If desired, counterstain sections with hematoxylin (#14166).
  15. Wash sections in dH2O two times for 5 min each.
  16. Dehydrate sections:
    1. Incubate sections in 95% ethanol two times for 10 sec each.
    2. Repeat in 100% ethanol, incubating sections two times for 10 sec each.
    3. Repeat in xylene, incubating sections two times for 10 sec each.
  17. Mount sections with coverslips and mounting medium (#14177).
DETECTION REAGENT/SUBSTRATE COMPATIBILITY
RECOMMENDED
DETECTION REAGENTS
SignalStain® Boost IHC Detection Reagent (HRP, Mouse) #8125 SignalStain® Boost IHC Detection Reagent (AP, Mouse) #31926
COMPATIBLE
CHROMOGEN
SignalStain® DAB Substrate Kit #8059 SignalStain® Vibrant Red Alkaline Phosphatase Substrate Kit #76713
SignalStain® Vivid Purple Peroxidase Substrate Kit #96632

NOTE: Use of detection reagents other than those specified in this protocol may require further optimization of the primary antibody to account for the different sensitivities of the detection reagents.

posted February 2015

revised April 2020

Protocol Id: 1990

Specificity / Sensitivity

HER2/ErbB2 (CB11) Mouse mAb recognizes endogenous levels of HER2/ErbB2 protein.

Species Reactivity:

Human

Source / Purification

Monoclonal antibody is produced by immunizing animals with a synthetic peptide corresponding to a site on the internal domain of human HER2/ErbB2 protein.

Background

The ErbB2 (HER2) proto-oncogene encodes a 185 kDa transmembrane, receptor-like glycoprotein with intrinsic tyrosine kinase activity (1). While ErbB2 lacks an identified ligand, ErbB2 kinase activity can be activated in the absence of a ligand when overexpressed and through heteromeric associations with other ErbB family members (2). Amplification of the ErbB2 gene and overexpression of its product are detected in almost 40% of human breast cancers (3). Binding of the c-Cbl ubiquitin ligase to ErbB2 at Tyr1112 leads to ErbB2 poly-ubiquitination and enhances degradation of this kinase (4). ErbB2 is a key therapeutic target in the treatment of breast cancer and other carcinomas and targeting the regulation of ErbB2 degradation by the c-Cbl-regulated proteolytic pathway is one potential therapeutic strategy. Phosphorylation of the kinase domain residue Tyr877 of ErbB2 (homologous to Tyr416 of pp60c-Src) may be involved in regulating ErbB2 biological activity. The major autophosphorylation sites in ErbB2 are Tyr1248 and Tyr1221/1222; phosphorylation of these sites couples ErbB2 to the Ras-Raf-MAP kinase signal transduction pathway (1,5).
  1. Muthuswamy, S.K. et al. (1999) Mol Cell Biol 19, 6845-57.
  2. Qian, X. et al. (1994) Proc Natl Acad Sci USA 91, 1500-4.
  3. Dittadi, R. and Gion, M. (2000) J Natl Cancer Inst 92, 1443-4.
  4. Klapper, L.N. et al. (2000) Cancer Res 60, 3384-8.
  5. Kwon, Y.K. et al. (1997) J Neurosci 17, 8293-9.
