Phospho-Aurora A (Thr288)/Aurora B (Thr232)/Aurora C (Thr198) (D13A11) XP® Rabbit mAb  (Alexa Fluor® 555 Conjugate) #13464

REACTIVITY SENSITIVITY MW (kDa) Isotype
H M R Endogenous Rabbit IgG
‹ 1 2 3 ›
‹ 1 2 3 ›
‹ 1 2 3 ›
IF-IC
enlarge

Immunofluorescence (Immunocytochemistry)

Confocal immunofluorescent analysis of HeLa cells using Phospho-Aurora A (Thr288)/Aurora B (Thr232)/Aurora C (Thr198) (D13A11) XP® Rabbit mAb (Alexa Fluor® 555 Conjugate) (red). Actin filaments were labeled with Alexa Fluor® 488 phalloidin #8878 (green). Blue pseudocolor = DRAQ5® #4084 (fluorescent DNA dye).

Learn more about how we get our images
‹ 1 2 3 ›
‹ 1 2 3 ›
‹ 1 2 3 ›
expand collapse

Protocol

Page
‹ 1 2 3 ›
PRINT

Immunofluorescence (Immunocytochemistry)

A. Solutions and Reagents

NOTE: Prepare solutions with reverse osmosis deionized (RODI) or equivalently purified water.

  1. 20X Phosphate Buffered Saline (PBS): (9808) To prepare 1L 1X PBS: add 50 ml 20X PBS to 950 ml dH2O, mix. Adjust pH to 8.0.
  2. Formaldehyde: 16%, methanol free, Polysciences, Inc. (cat# 18814), use fresh and store opened vials at 4°C in dark, dilute in 1X PBS for use.
  3. Permeabilization Buffer (1X PBS/0.2% Triton X-100):
    To prepare 25 ml, add 2.5 ml 10X PBS, and 22.5 ml dH2O and mix well. While stirring, add 50 µl Triton X-100.
  4. Image-iT™ FX Signal Enhancer (#11932)
  5. Blocking Buffer (1X PBS / 5% normal serum / 0.3% Triton™ X-100): To prepare 10 ml, add 0.5 ml normal serum from the same species as the secondary antibody (e.g., Normal Goat Serum (#5425)) and 0.5 mL 20X PBS to 9.0 mL dH2O, mix well. While stirring, add 30 µl Triton™ X-100.
  6. Antibody Dilution Buffer (1X PBS / 1% BSA / 0.3% Triton X-100): To prepare 10 ml, add 30 µl Triton™ X-100 to 10 ml 1X PBS. Mix well then add 0.1 g BSA (9998), mix.
  7. Prolong® Gold AntiFade Reagent (#9071), Prolong® Gold AntiFade Reagent with DAPI (#8961).

B. Specimen Preparation - Cultured Cell Lines (IF-IC)

NOTE: Cells should be grown, treated, fixed, and stained directly in multi-well plates, chamber slides, or on coverslips.

  1. Aspirate liquid, then cover cells to a depth of 2–3 mm with 4% formaldehyde in 1X PBS.
    NOTE: Formaldehyde is toxic, use only in fume hood.
  2. Allow cells to fix for 15 minutes at room temperature.
  3. Aspirate fixative, rinse three times in 1X PBS for 5 minutes each.
  4. Proceed with Immunostaining (Section C).

C. Immunostaining

NOTE: All subsequent incubations should be carried out at room temperature unless otherwise noted in a humid light-tight box or covered dish/plate to prevent drying and fluorochrome fading.

  1. Permeabilize the cells in Permeabilization Buffer for 5 minutes at room temperature.
  2. Rinse three times in 1X PBS for 5 minutes each.
  3. Apply 3–4 drops of Image-iT™ FX Signal Enhancer (#11932) and incubate for 30 minutes at room temperature.
  4. Rinse three times with 1X PBS for 5 minutes each.
  5. Block specimen in Blocking Buffer for 60 minutes.
  6. While blocking, prepare primary antibody by diluting as indicated on datasheet in Antibody Dilution Buffer.
  7. Aspirate blocking solution, apply diluted primary antibody.
  8. Incubate overnight at 4°C.
  9. Rinse three times in 1X PBS for 5 minutes each.
  10. Coverslip slides with Prolong® Gold Antifade Reagent (#9071), Prolong® Gold AntiFade Reagent with DAPI (#8961).
  11. For best results, examine specimens immediately using appropriate excitation wavelength. For long-term storage, store slides flat at 4°C protected from light.

posted Februay 2011

Protocol Id: 6
expand collapse

Product Usage Information

Application Dilutions
Immunofluorescence (Immunocytochemistry) 1:50

Storage: Supplied in PBS (pH 7.2), less than 0.1% sodium azide and 2 mg/ml BSA. Store at 4°C. Do not aliquot the antibody. Protect from light. Do not freeze.
expand collapse

Specificity / Sensitivity

Phospho-Aurora A (Thr288)/Aurora B (Thr232)/Aurora C (Thr198) (D13A11) XP® Rabbit mAb (Alexa Fluor® 555 Conjugate) detects endogenous levels of Aurora A/B/C protein only when phosphorylated at Thr288, Thr232, or Thr198, respectively.


Species Reactivity: Human, Mouse, Rat
expand collapse

Source / Purification

Monoclonal antibody is produced by immunizing animals with a synthetic peptide corresponding to residues surrounding Thr232 of human Aurora B protein.

expand collapse

Product Description

This Cell Signaling Technology antibody is conjugated to Alexa Fluor® 555 fluorescent dye and tested in-house for immunofluorescent analysis in human cells. The antibody is expected to exhibit the same species cross-reactivity as the unconjugated Phospho-Aurora A (Thr288)/Aurora B (Thr232)/Aurora C (Thr198) (D13A11) XP® Rabbit mAb  #2914.


expand collapse

Background

Aurora kinases belong to a highly conserved family of mitotic serine/threonine kinases with three members identified among mammals: Aurora A, B, and C (1,2). Studies on the temporal expression pattern and subcellular localization of Aurora kinases in mitotic cells suggest an association with mitotic structure. Aurora kinase functional influences span from G2 phase to cytokinesis and may be involved in key cell cycle events such as centrosome duplication, chromosome bi-orientation and segregation, cleavage furrow positioning, and ingression (3). Aurora A is detected at the centrosomes, along mitotic spindle microtubules, and in the cytoplasm of mitotically proliferating cells. Aurora A protein levels are low during G1 and S phases and peak during the G2/M phase of the cell cycle. Phosphorylation of Aurora A at Thr288 in its catalytic domain increases kinase activity. Aurora A is involved in centrosome separation, maturation, and spindle assembly and stability. Expression of Aurora B protein also peaks during the G2/M phase of the cell cycle; Aurora B kinase activity peaks at the transition from metaphase to the end of mitosis. Aurora B associates with chromosomes during prophase prior to relocalizing to the spindle at anaphase. Aurora B regulates chromosome segregation through the control of microtubule-kinetochore attachment and cytokinesis. Expression of both Aurora A and Aurora B during the G2/M phase transition is tightly coordinated with histone H3 phosphorylation (4,5); research investigators have observed overexpression of these kinases in a variety of human cancers (2,4). Aurora C localizes to the centrosome from anaphase to cytokinesis and both mRNA and protein levels peak during G2/M phase. Although typical Aurora C expression is limited to the testis, research studies report overexpression of Aurora C is detected in various cancer cell lines (6).


1.  Warner, S.L. et al. (2003) Mol Cancer Ther 2, 589-95.

2.  Katayama, H. et al. (2003) Cancer Metastasis Rev 22, 451-64.

3.  Andrews, P.D. et al. (2003) Curr Opin Cell Biol 15, 672-83.

4.  Pascreau, G. et al. (2003) Prog Cell Cycle Res 5, 369-74.

5.  Crosio, C. et al. (2002) Mol Cell Biol 22, 874-85.

6.  Kimura, M. et al. (1999) J Biol Chem 274, 7334-40.


Entrez-Gene Id 6790 , 9212 , 6795
Swiss-Prot Acc. O14965 , Q96GD4 , Q9UQB9
expand collapse

Data Sheets & Documentation

For Research Use Only. Not For Use In Diagnostic Procedures.
Cell Signaling Technology is a trademark of Cell Signaling Technology, Inc.
XP is a registered trademark of Cell Signaling Technology, Inc.
Alexa Fluor is a registered trademark of Life Technologies Corporation.
DRAQ5 is a registered trademark of Biostatus Limited.
Image-iT is a registered trademark of Life Technologies Corporation.
The Alexa Fluor dye antibody conjugates in this product are sold under license from Life Technologies Corporation for research use only, except for use in combination with DNA microarrays. The Alexa Fluor® dyes (except for Alexa Fluor® 430 dye) are covered by pending and issued patents. Alexa Fluor® is a registered trademark of Molecular Probes, Inc.
