HTScan® Src Kinase Assay Kit
Cellular Assay Kits
Assay Kit

HTScan® Src Kinase Assay Kit #7776

Citations (0)
HTScan® Src Kinase Assay Kit: Image 1
Western blot analysis of extracts from Jurkat cells treated with 1 mM pervanadate for 30 minutes prior to lysis, using P-Tyr-100 Phospho-Tyrosine Mouse mAb. Proteins were separated by 2-D electrophoresis prior to blotting.
HTScan® Src Kinase Assay Kit: Image 2
Immunohistochemical analysis of paraffin-embedded human breast carcinoma using Phospho-Tyrosine Mouse mAb (P-Tyr-100).
HTScan® Src Kinase Assay Kit: Image 3
Immunohistochemical analysis of paraffin-embedded human lung carcinoma using Phospho-Tyrosine Mouse mAb (P-Tyr-100).
HTScan® Src Kinase Assay Kit: Image 4
Immunohistochemical analysis of paraffin-embedded NCI-H1650 xenograft untreated (left) or lambda-phosphatase-treated (right), using Phospho-Tyrosine Mouse mAb (P-Tyr-100).
HTScan® Src Kinase Assay Kit: Image 5
Immunohistochemical analysis of paraffin-embedded human B-cell non-Hodgkin lymphoma, untreated (left) or lambda phosphatase treated (right), using Phospho-Tyrosine Mouse mAb (P-Tyr-100).
HTScan® Src Kinase Assay Kit: Image 6
Immunohistochemical analysis of paraffin-embedded human squamous cell lung carcinoma using Phospho-Tyrosine Mouse mAb (P-Tyr-100).
HTScan® Src Kinase Assay Kit: Image 7
Immunohistochemical analysis using Phospho-Tyrosine Mouse mAb (P-Tyr-100) on SignalSlide™ Phospho-EGF Receptor IHC Controls #8102 (paraffin-embedded KYSE450 cell pellets, untreated (left) or EGF-treated (right)).
HTScan® Src Kinase Assay Kit: Image 8
Immunohistochemical analysis of paraffin-embedded human soft tissue squamous cell carcinoma using Phospho-Tyrosine Mouse mAb (P-Tyr-100).
HTScan® Src Kinase Assay Kit: Image 9
Immunohistochemical analysis of paraffin-embedded normal human kidney using Phospho-Tyrosine Mouse mAb (P-Tyr-100).
HTScan® Src Kinase Assay Kit: Image 10
Immunohistochemical analysis of paraffin-embedded normal human lung using Phospho-Tyrosine Mouse mAb (P-Tyr-100).
HTScan® Src Kinase Assay Kit: Image 11
Immunohistochemical analysis of paraffin-embedded NCI-H1650 xenograft using Phospho-Tyrosine Mouse mAb (P-Tyr-100).
HTScan® Src Kinase Assay Kit: Image 12
Confocal immunofluorescent analysis of paraffin-embedded human lung adenocarcinoma using Phospho-Tyrosine Mouse mAb (P-Tyr-100) (red). Blue pseudocolor = DRAQ5® (fluorescent DNA dye).
HTScan® Src Kinase Assay Kit: Image 13
Immunofluorescent analysis of Swiss NIH/3T3 cells, serum-starved and stimulated with lysophosphatidic acid (LPA) (10 µM for 10 minutes) and fixed with PFA, using Phospho-Tyrosine Mouse mAb (P-Tyr-100) (red) and phalloidin for F-actin (green) LPA causes heavy tyrosine phosphorylation of proteins in focal adhesions, present at the tips of actin stress fibers. (Provided by Dr. Harry Mellor, University of Bristol.)
HTScan® Src Kinase Assay Kit: Image 14
Confocal immunofluorescence analysis of HeLa cells either stimulated with 20% serum (left) or untreated (right), using Phospho-Tyrosine Mouse mAb (P-Tyr-100) (red). Actin filaments have been labeled with fluorescein phalloidin. Blue pseudocolor = DRAQ5® (fluorescent DNA dye).
HTScan® Src Kinase Assay Kit: Image 15
Flow cytometric analysis of K562 cells, untreated (green) or Gleevec®- treated (blue), using Phospho-Tyrosine Mouse mAb (P-Tyr-100) compared to a nonspecific negative control antibody (red).
Inquiry Info.# 7776

Product Description

The kit provides a means of performing kinase activity assays with recombinant human Src kinase. It includes active Src kinase (supplied as a GST fusion protein), a biotinylated peptide substrate and a phospho-tyrosine antibody for detection of the phosphorylated form of the substrate peptide.
MW (kDa) Peptide substrate, Biotin-peptide: 1830 Daltons. GST-Src Kinase: 90
Molecular Formula Peptide substrate, Biotin-peptide: 1830 Daltons. GST-Src Kinase: 90 kDa.

Background

The Src family of protein tyrosine kinases, which includes Src, Lyn, Fyn, Yes, Lck, Blk, and Hck, are important in the regulation of growth and differentiation of eukaryotic cells (1). Src activity is regulated by tyrosine phosphorylation at two sites, but with opposing effects. While phosphorylation at Tyr416 in the activation loop of the kinase domain upregulates enzyme activity, phosphorylation at Tyr527 in the carboxy-terminal tail by Csk renders the enzyme less active (2).
  1. Thomas, S.M. and Brugge, J.S. (1997) Annu Rev Cell Dev Biol 13, 513-609.
  2. Hunter, T. (1987) Cell 49, 1-4.
