Pan-branch Ubiquitin TUBE-UBQLN1 Assay Kit (Anti-mouse IgG Secondary) #35030

Filter:
  • ELISA+

Important Ordering Details

Custom Ordering Details:

If kit quantities from the same lot are needed in unlisted sizes, contact us for processing time and pricing.

Looking for this ELISA kit in a 384-well format? Inquire for availability, processing time, and pricing.

    Product Specifications

    REACTIVITY All
    Application Key:
    • ELISA+-ELISA and/or ELISA-like Assays
    Species Cross-Reactivity Key:
    • All-All Species Expected

    Product Information

    Product Description

    Tandem-repeated ubiquitin-binding entities (TUBEs) were designed using four tandem ubiquitin-associated (UBA) domains from ubiquilin 1 (UBQLN1), allowing it to bind to proteins containing polyubiquitinated chains. The Pan-branch Ubiquitin TUBE-UBQLN1 Assay Kit (Anti-mouse IgG Secondary) provides the reagents to run a solid phase sandwich enzyme-linked immunosorbent assay (ELISA) that can detect ubiquitination of a protein of interest (detection antibody to specific target protein not included in assay kit). Pan-branch Ubiquitin TUBE-UBQLN1 has been coated onto the microwells. After incubation with cell lysates, ubiquitinated proteins are captured by the coated TUBE-UBQLN1. Following extensive washing, a user-provided detection antibody (mouse IgG) that binds to a target of interest is added to detect the captured ubiquitinated protein. Anti-mouse IgG, HRP-linked Antibody is then used to recognize the bound detection antibody. HRP substrate, TMB, is added to develop color. The magnitude of the absorbance for this developed color is proportional to the quantity of the ubiquitinated target protein.

    User must supply a detection antibody suitable for use in sandwich ELISAs that recognizes the target protein whose ubiquitination is being tested. Pan-branch Ubiquitin TUBE-UBQLN1 Assay Kit (Anti-mouse IgG Secondary) #35030 requires a mouse detection antibody. If using a rabbit detection antibody, Pan-branch Ubiquitin TUBE-UBQLN1 Assay Kit (Anti-rabbit IgG Secondary) #17452 should be used. Click here for more information regarding Cell Signaling Technology® ELISA-validated antibodies.

    *Reagents in this kit are custom formulations specific to kit.

    Protocol

    Specificity / Sensitivity

    Pan-branch Ubiquitin TUBE-UBQLN1, designed from the ubiquitin binding domain of UBQLN1, was produced in Escherichia coli and contains a GST-tag, His-tag, and V5-tag. TUBE-UBQLN1 binds to endogenous levels of proteins containing polyubiquitinated chains. It binds to K48- and K63-branched tetraubiquitin chains. The Pan-branch Ubiquitin TUBE-UBQLN1 Assay Kit (Anti-mouse IgG Secondary) detects endogenous levels of a ubiquitinated protein of interest when used in combination with a mouse IgG detection antibody supplied by the user.

    Species Reactivity:

    All Species Expected

    Background

    Ubiquitin is a conserved polypeptide unit that plays an important role in the ubiquitin-proteasome pathway. Ubiquitin can be covalently linked to many cellular proteins by the ubiquitination process, which targets proteins for degradation by the 26S proteasome. Three components are involved in the target protein-ubiquitin conjugation process. Ubiquitin is first activated by forming a thiolester complex with the activation component E1; the activated ubiquitin is subsequently transferred to the ubiquitin-carrier protein E2, then from E2 to ubiquitin ligase E3 for final delivery to the epsilon-NH2 of the target protein lysine residue (1-3). The ubiquitin-proteasome pathway has been implicated in a wide range of normal biological processes and in disease-related abnormalities. Several proteins such as IκB, p53, cdc25A, and Bcl-2 have been shown to be targets for the ubiquitin-proteasome process as part of regulation of cell cycle progression, differentiation, cell stress response, and apoptosis (4-7).

    Substrate proteins are linked to ubiquitin using seven distinct ubiquitin lysine residues (Lys6, Lys11, Lys27, Lys29, Lys33, Lys48, and Lys63). Formation of a polyubiquitin chain occurs when a lysine residue of ubiquitin is linked to the carboxy-terminal glycine of another ubiquitin. Proteins polyubiquitinated at specific lysine residues display a tendency to be targeted for different processes; K48-linked polyubiquitin chains mainly target proteins for proteasomal degradation, while K63-linked polyubiquitin chains regulate protein function, subcellular localization, or protein-protein interactions (8). K63-linked polyubiquitin chains exert nonproteolytic functions in vivo, such as protein trafficking, kinase/phosphatase activation, and DNA damage control, all of which might be important in regulation of cancer survival and development (9,10).

    Ubiquitin-associated (UBA) domains are protein regions that interact with ubiquitin. Tandem-repeated ubiquitin-binding entities (TUBEs) were designed by using four tandem UBA domains, based on the theory that tetraubiquitin chains are a minimum requirement for efficient proteasomal degradation (11). TUBEs designed with UBA domains from UBQLN1 and RAD23A bind to K48- and K63-linked tetraubiquitin chains and can be used to efficiently purify ubiquitylated proteins from cell extracts (12).
    For Research Use Only. Not for Use in Diagnostic Procedures.
    Cell Signaling Technology is a trademark of Cell Signaling Technology, Inc.
    U.S. Patent No. 8,716,441, foreign equivalents, and child patents deriving therefrom.
