Upstream / Downstream

pathwayImage

Explore pathways related to this product.

Antibody Guarantee

CST Antibody Performance Guarantee

LEARN MORE

To Purchase # 4590S

4590S 100 µl $246.00.0
$0.00

Questions?

Find answers on our FAQs page.

ANSWERS

PhosphoSitePlus® Resource

  • Additional protein information
  • Analytical tools

LEARN MORE

REACTIVITY SENSITIVITY MW (kDa) SOURCE
H M R Endogenous 6 Rabbit

Immunohistochemistry (Paraffin)

Immunohistochemical analysis of paraffin-embedded rat pancreas, showing staining of β-cells using Insulin Antibody.

Learn more about how we get our images

Immunohistochemistry (Paraffin)

Immunohistochemical analysis of paraffin-embedded mouse pancreas, showing staining of β cells, using Insulin Antibody.

Learn more about how we get our images

Immunohistochemistry (Paraffin)

Immunohistochemical analysis of paraffin-embedded human pancreas, showing staining of β cells, using Insulin Antibody.

Learn more about how we get our images

Immunofluorescence (Immunocytochemistry)

Confocal immunofluorescent analysis of normal mouse pancreas using Insulin Antibody (green). Blue pseudocolor = DRAQ5™ (fluorescent DNA dye).

Learn more about how we get our images

Immunofluorescence (Immunocytochemistry)

Confocal immunofluorescent analysis of beta-TC-6 and HeLa cells using Insulin Antibody (green). Actin filaments have been labeled with Alexa Fluor 555 phalloidin (red). Blue pseudocolor = DRAQ5™ (fluorescent DNA dye).

Learn more about how we get our images

Flow Cytometry

Flow cytometric analysis of untreated β-TC cells, using Insulin Antibody (blue) compared to a nonspecific negative control antibody (red).

Learn more about how we get our images
Page

Immunohistochemistry (Paraffin)

A. Solutions and Reagents

  1. Xylene
  2. Ethanol, anhydrous denatured, histological grade (100% and 95%)
  3. Deionized water (dH2O)
  4. Hematoxylin (optional)
  5. Wash Buffer:
    1. 1X Tris Buffered Saline with Tween® 20 (TBST): To prepare 1L 1X TBST add 100 ml 10X Tris Buffered Saline with Tween® 20 (#9997) to 900 ml dH20, mix.
    2. Antibody Diluent TBST/5% Normal Goat Serum: to 5 mL 1X TBST, add 250 µl Normal Goat Serum #5425).
  6. 1X Citrate Unmasking Solution: To prepare 250 mL of 1X citrate unmasking solution, dilute 25 ml of SignalStain® Citrate Unmasking Solution (10X) (#14746) with 225 mL of dH2O.
  7. 3% Hydrogen Peroxide: To prepare, add 10 ml 30% H2O2 to 90 ml dH2O.
  8. Blocking Solution: TBST/5% Normal Goat Serum or 1X Animal-Free Blocking Solution.
    1. TBST/5% Normal Goat Serum: to 5 ml 1X TBST, add 250 µl Normal Goat Serum (#5425).
    2. 1X Animal-Free Blocking Solution: to 4 mL of dH2O add 1 ml of Animal-Free Blocking Solution (5X) (#15019).
  9. Detection System: VECTASTAIN® Elite ABC, including biotinylated secondary antibody (Vector Laboratories).
  10. Substrate: Vector® NovaRED™ (Vector Laboratories).
  11. Hematoxylin: Hematoxylin (#14166).
  12. Mounting Medium: SignalStain® Mounting Medium (#14177).

B. Deparaffinization/Rehydration

NOTE: Do not allow slides to dry at any time during this procedure.

  1. Deparaffinize/hydrate sections:
    1. Incubate sections in three washes of xylene for 5 minutes each.
    2. Incubate sections in two washes of 100% ethanol for 10 minutes each.
    3. Incubate sections in two washes of 95% ethanol for 10 minutes each.
  2. Wash sections twice in dH2O for 5 minutes each.

C. Antigen Unmasking

For Citrate: Heat slides in a microwave submersed in 1X citrate unmasking solution until boiling is initiated; follow with 10 min at a sub-boiling temperature (95°-98°C). Cool slides on bench top for 30 min.

D. Staining

  1. Wash sections in dH2O three times for 5 minutes each.
  2. Incubate sections in 3% hydrogen peroxide for 10 minutes.
  3. Wash sections in dH2O twice for 5 minutes each.
  4. Wash sections in wash buffer for 5 minutes.
  5. Block each section with 100-400 µl of preferred blocking solution for 1 hour at room temperature.
  6. Remove blocking solution and add 100-400 µl primary antibody diluted in recommended antibody diluent to each section. Incubate overnight at 4°C.
  7. Prepare ABC solution per manufacturer's recommendations.
  8. Remove primary antibody and wash section three times with wash buffer for 5 minutes each.
  9. Add 100-400 µl biotinylated secondary antibody, diluted in TBST per manufacturer’s recommendation, to each section. Incubate 30 minutes at room temperature.
  10. Remove secondary antibody solution and wash sections three times with wash buffer for 5 minutes each.
  11. Cover sections with 100-400 µl pre-mixed ABC solution as needed and incubate in a humidified chamber for 30 min at room temperature.
  12. Wash section three times with wash buffer for 5 min each.
  13. Prepare Vector® NovaRED™ per manufacturer's recommendations.
  14. Apply 100-400 µl substrate to each section and monitor closely. 1-10 minutes generally provides an acceptable staining intensity.
  15. If desired, counterstain sections with hematoxylin (#14166).
  16. Wash sections in dH2O two times for 5 minutes each.
  17. Dehydrate sections:
    1. Incubate sections in 95% ethanol two times for 10 seconds each.
    2. Repeat in 100% ethanol, incubating sections two times for 10 seconds each.
    3. Repeat in xylene, incubating sections two times for 10 seconds each.
  18. Mount sections with coverslips and mounting medium (#14177).

posted June 2005

revised March 2016

Protocol Id: 310
Page

Immunofluorescence (Frozen)

A. Solutions and Reagents

NOTE: Prepare solutions with reverse osmosis deionized (RODI) or equivalent grade water.

  1. 20X Phosphate Buffered Saline (PBS): (9808) To prepare 1L 1X PBS: add 50 ml 20X PBS to 950 ml dH2O, mix. Adjust pH to 8.0.
  2. Formaldehyde: 16%, methanol free, Polysciences, Inc. (cat# 18814), use fresh and store opened vials at 4°C in dark, dilute in 1X PBS for use.
  3. Blocking Buffer: (1X PBS / 5% normal serum / 0.3% Triton™ X-100): To prepare 10 ml, add 0.5 ml normal serum from the same species as the secondary antibody (e.g., Normal Goat Serum (#5425) to 9.5 ml 1X PBS) and mix well. While stirring, add 30 µl Triton™ X-100.
  4. Antibody Dilution Buffer: (1X PBS / 1% BSA / 0.3% Triton™ X-100): To prepare 10 ml, add 30 µl Triton™ X-100 to 10 ml 1X PBS. Mix well then add 0.1 g BSA (#9998), mix.
  5. Recommended Fluorochrome-conjugated Anti-Rabbit secondary antibodies:

    NOTE: When using any primary or fluorochrome-conjugated secondary antibody for the first time, titrate the antibody to determine which dilution allows for the strongest specific signal with the least background for your sample.

  6. Prolong® Gold AntiFade Reagent (#9071), Prolong® Gold AntiFade Reagent with DAPI (#8961).

B. Specimen Preparation - Frozen/Cryostat Sections (IF-F)

  1. For fixed frozen tissue proceed with Immunostaining (Section C).
  2. For fresh, unfixed frozen tissue, please fix immediately, as follows:
    1. Cover sections with 4% formaldehyde dilute in 1X PBS.

      NOTE: Formaldehyde is toxic, use only in fume hood.

    2. Allow sections to fix for 15 minutes at room temperature.
    3. Aspirate liquid, rinse three times in 1X PBS for 5 minutes each.
    4. Proceed with Immunostaining (Section C).

C. Immunostaining

NOTE: All subsequent incubations should be carried out at room temperature unless otherwise noted in a humid light-tight box or covered dish/plate to prevent drying and fluorochrome fading.

  1. Block specimen in Blocking Buffer for 60 min.
  2. While blocking, prepare primary antibody by diluting as indicated on datasheet in Antibody Dilution Buffer.
  3. Aspirate blocking solution, apply diluted primary antibody.
  4. Incubate overnight at 4°C.
  5. Rinse three times in 1X PBS for 5 min each.
  6. Incubate specimen in fluorochrome-conjugated secondary antibody diluted in Antibody Dilution Buffer for 1–2 hr at room temperature in the dark.
  7. Rinse three times in 1X PBS for 5 min each.
  8. Coverslip slides with Prolong® Gold Antifade Reagent (#9071) or Prolong® Gold Antifade Reagent with DAPI (#8961).
  9. For best results, allow mountant to cure overnight at room temperature. For long-term storage, store slides flat at 4°C protected from light.

posted November 2006

revised July 2016

Protocol Id: 151

Immunofluorescence (Immunocytochemistry)

A. Solutions and Reagents

Achieve higher quality immunofluorescent images using the efficient and cost-effective, pre-made reagents in our #12727 Immunofluorescence Application Solutions Kit

NOTE: Prepare solutions with reverse osmosis deionized (RODI) or equivalent grade water.

  1. 20X Phosphate Buffered Saline (PBS): (9808) To prepare 1L 1X PBS: add 50 ml 20X PBS to 950 ml dH2O, mix. Adjust pH to 8.0.
  2. Formaldehyde: 16%, methanol free, Polysciences, Inc. (cat# 18814), use fresh and store opened vials at 4°C in dark, dilute in 1X PBS for use.
  3. Blocking Buffer (1X PBS / 5% normal serum / 0.3% Triton™ X-100): To prepare 10 ml, add 0.5 ml normal serum from the same species as the secondary antibody (e.g., Normal Goat Serum (#5425)) and 0.5 mL 20X PBS to 9.0 mL dH2O, mix well. While stirring, add 30 µl Triton™ X-100.
  4. Antibody Dilution Buffer (1X PBS / 1% BSA / 0.3% Triton X-100): To prepare 10 ml, add 30 µl Triton™ X-100 to 10 ml 1X PBS. Mix well then add 0.1 g BSA (9998), mix.
  5. Recommended Fluorochrome-conjugated Anti-Rabbit secondary antibodies:

  6. Prolong® Gold AntiFade Reagent (#9071), Prolong® Gold AntiFade Reagent with DAPI (#8961).

B. Specimen Preparation - Cultured Cell Lines (IF-IC)

NOTE: Cells should be grown, treated, fixed and stained directly in multi-well plates, chamber slides or on coverslips.

  1. Aspirate liquid, then cover cells to a depth of 2–3 mm with 4% formaldehyde diluted in 1X PBS.

    NOTE: Formaldehyde is toxic, use only in a fume hood.

  2. Allow cells to fix for 15 min at room temperature.
  3. Aspirate fixative, rinse three times in 1X PBS for 5 min each.
  4. Proceed with Immunostaining (Section C).

C. Immunostaining

NOTE: All subsequent incubations should be carried out at room temperature unless otherwise noted in a humid light-tight box or covered dish/plate to prevent drying and fluorochrome fading.

  1. Block specimen in Blocking Buffer for 60 min.
  2. While blocking, prepare primary antibody by diluting as indicated on datasheet in Antibody Dilution Buffer.
  3. Aspirate blocking solution, apply diluted primary antibody.
  4. Incubate overnight at 4°C.
  5. Rinse three times in 1X PBS for 5 min each.
  6. Incubate specimen in fluorochrome-conjugated secondary antibody diluted in Antibody Dilution Buffer for 1–2 hr at room temperature in the dark.
  7. Rinse three times in 1X PBS for 5 min each.
  8. Coverslip slides with Prolong® Gold Antifade Reagent (#9071) or Prolong® Gold Antifade Reagent with DAPI (#8961).
  9. For best results, allow mountant to cure overnight at room temperature. For long-term storage, store slides flat at 4°C protected from light.

posted November 2006

revised November 2013

Protocol Id: 24
Page

Flow Cytometry, Methanol Permeabilization Protocol for Rabbit Antibodies

A. Solutions and Reagents

NOTE: Prepare solutions with reverse osmosis deionized (RODI) or equivalent grade water.

  1. 20X Phosphate Buffered Saline (PBS): (#9808) To prepare 1 L 1X PBS: add 50 ml 20X PBS to 950 ml dH2O, mix.
  2. 16% Formaldehyde (methanol free).
  3. 100% methanol.
  4. Incubation Buffer: Dissolve 0.5 g Bovine Serum Albumin (BSA) (#9998) in 100 ml 1X PBS. Store at 4°C.
  5. Recommended Anti-Rabbit secondary antibodies::

B. Fixation

NOTE: If using whole blood, lyse red blood cells and wash by centrifugation prior to fixation.

  1. Collect cells by centrifugation and aspirate supernatant.
  2. Resuspend cells in 0.5-1 ml 1X PBS. Add formaldehyde to obtain a final concentration of 4%.
  3. Fix for 15 min at room temperature.
  4. Wash by centrifugation with excess 1X PBS. Discard supernatant in appropriate waste container. Resuspend cells in 0.5-1 ml 1X PBS.

C. Permeabilization

  1. Permeabilize cells by adding ice-cold 100% methanol slowly to pre-chilled cells, while gently vortexing, to a final concentration of 90% methanol.
  2. Incubate 30 min on ice.
  3. Proceed with immunostaining (Section D) or store cells at -20°C in 90% methanol.

D. Immunostaining

NOTE: Count cells using a hemocytometer or alternative method.

  1. Aliquot desired number of cells into tubes or wells.
  2. Wash cells by centrifugation in excess 1X PBS to remove methanol. Discard supernatant in appropriate waste container. Repeat if necessary.
  3. Resuspend cells in 100 µl of diluted primary antibody (prepared in incubation buffer at the recommended dilution).
  4. Incubate for 1 hr at room temperature.
  5. Wash by centrifugation in incubation buffer. Discard supernatant. Repeat.
  6. Resuspend cells in 100 µl of diluted fluorochrome-conjugated secondary antibody (prepared in incubation buffer at recommended dilution).
  7. Incubate for 30 min at room temperature.
  8. Wash by centrifugation in incubation buffer. Discard supernatant. Repeat.
  9. Resuspend cells in 1X PBS and analyze on flow cytometer; alternatively, for DNA staining, proceed to optional DNA stain (Section E).

E. Optional DNA Dye

  1. Resuspend cells in 0.5 ml of DNA dye (e.g. Propidium Iodide (PI)/RNase Staining Solution #4087).
  2. Incubate for at least 5 min at room temperature.
  3. Analyze cells in DNA staining solution on flow cytometer.

posted July 2009

revised June 2017

Protocol Id: 404

Product Usage Information

Application Dilutions
Immunohistochemistry (Paraffin) 1:100
Immunofluorescence (Frozen) 1:100
Immunofluorescence (Immunocytochemistry) 1:100
Flow Cytometry 1:100

Storage: Supplied in 10 mM sodium HEPES (pH 7.5), 150 mM NaCl, 100 µg/ml BSA and 50% glycerol. Store at –20°C. Do not aliquot the antibody.

Specificity / Sensitivity

Insulin Antibody detects endogenous levels of total insulin protein.


Species Reactivity: Human, Mouse, Rat

Source / Purification

Polyclonal antibodies are produced by immunizing animals with a synthetic peptide corresponding to the sequence of human insulin. Antibodies are purified by protein A and peptide affinity chromatography.

The maintenance of glucose homeostasis is an essential physiological process that is regulated by hormones. An elevation in blood glucose levels during feeding stimulates insulin release from pancreatic β cells through a glucose sensing pathway (1). Insulin is synthesized as a precursor molecule, proinsulin, which is processed prior to secretion. A- and B-peptides are joined together by a disulfide bond to form insulin, while the central portion of the precursor molecule is cleaved and released as the C-peptide. Insulin stimulates glucose uptake from blood into skeletal muscle and adipose tissue. Insulin deficiency leads to type 1 diabetes mellitus (2).


1.  Straub, S.G. and Sharp, G.W. (2002) Diabetes Metab. Res. Rev. 18, 451-463.

2.  Concannon, P. et al. (1998) Nat. Genet. 19, 292-296.


Entrez-Gene Id 3630
Swiss-Prot Acc. P01308
