Normal Rabbit IgG #2729

Chromatin IP

Specific for product: SimpleChIP^® Plus Enzymatic Chromatin IP Kit (Magnetic Beads) #9005.

Required Reagents

Reagents Included:

1. Glycine Solution (10X) #7005
2. Buffer A (4X) #7006
3. Buffer B (4X) #7007
4. ChIP Buffer (10X) #7008
5. ChIP Elution Buffer (2X) #7009
6. 5 M NaCl #7010
7. 0.5 M EDTA #7011
8. ChIP-Grade Protein G Magnetic Beads #9006
9. DNA Binding Buffer #10007
10. DNA Wash Buffer (add 4x volume ethanol before use) #10008
11. DNA Elution Buffer #10009
12. DNA Purification Columns #10010
13. Protease Inhibitor Cocktail (200X) #7012
14. RNAse A (10 mg/ml) #7013
15. Micrococcal Nuclease #10011
16. Proteinase K (20 mg/ml) #10012
17. SimpleChIP^® Human RPL30 Exon 3 Primers 1 #7014
18. SimpleChIP^® Mouse RPL30 Intron 2 Primers 1 #7015
19. Histone H3 (D2B12) XP^® Rabbit mAb (ChIP Formulated) #4620
20. Normal Rabbit IgG #2729
21. DTT (Dithiothreitol) #7016

Reagents Not Included:

1. Magnetic Separation Rack #7017 / 14654
2. Phosphate Buffered Saline (PBS-1X) pH7.2 (Sterile) #9872
3. Nuclease-free Water #12931
4. Ethanol (96-100%)
5. Formaldehyde (37% Stock)
6. Taq DNA Polymerase
7. dNTP Mix

I. Tissue Cross-linking and Sample Preparation

When harvesting tissue, remove unwanted material such as fat and necrotic material from the sample. Tissue can then be processed and cross-linked immediately, or frozen on dry ice for processing later. For optimal chromatin yield and ChIP results, use 25 mg of tissue for each immunoprecipitation to be performed. The chromatin yield does vary between tissue types and some tissues may require more than 25 mg for each immunoprecipitation. Please see Appendix A for more information regarding the expected chromatin yield for different types of tissue. One additional chromatin sample should be processed for Analysis of Chromatin Digestion and Concentration (Section IV).

Before starting:

• Remove and warm 200X Protease Inhibitor Cocktail (PIC) and 10X Glycine Solution. Make sure PIC is completely thawed.
• Prepare 3 ml of Phosphate Buffered Saline (PBS) + 15 µl 200X PIC per 25 mg of tissue to be processed and place on ice.
• Prepare 45 µl of 37% formaldehyde per 25 mg of tissue to be processed and keep at room temperature. Use fresh formaldehyde that is not past the manufacturer's expiration date.

A. Cross-linking

1. Weigh the fresh or frozen tissue sample. Use 25 mg of tissue for each IP to be performed.
2. Place tissue sample in a 60 mm or 100 mm dish and finely mince using a clean scalpel or razor blade. Keep dish on ice. It is important to keep the tissue cold to avoid protein degradation.
3. Transfer minced tissue to a 15 ml conical tube.
4. Add 1 ml of PBS + PIC per 25 mg tissue to the conical tube.
5. To crosslink proteins to DNA, add 45 µl of 37% formaldehyde per 1 ml of PBS + PIC and rock at room temp for 20 min. Final formaldehyde concentration is 1.5%.
6. Stop cross-linking by adding 100 µl of 10X Glycine per 1 ml of PBS + PIC and mix for 5 min at room temperature.
7. Centrifuge tissue at 1,500 rpm in a benchtop centrifuge for 5 min at 4°C.
8. Remove supernatant and wash one time with 1 ml PBS + PIC per 25 mg tissue.
9. Repeat centrifugation at 1,500 rpm in a benchtop centrifuge for 5 min at 4°C.
10. Remove supernatant and resuspend tissue in 1 ml PBS + PIC per 25 mg tissue and store on ice. Disaggregate tissue into single-cell suspension using a Medimachine (Part B) or Dounce homogenizer (Part C).

B. Tissue Disaggregation Using Medimachine from BD Biosciences (part #340587)

1. Cut off the end of a 1000 µL pipette tip to enlarge the opening for transfer of tissue chunks.
2. Transfer 1 ml of tissue resuspended in PBS + PIC into the top chamber of a 50 mm medicone (part #340592).
3. Grind tissue for 2 min according to manufacturer's instructions.
4. Collect cell suspension from the bottom chamber of the medicone using a 1 ml syringe and 18 gauge blunt needle. Transfer cell suspension to a 15 ml conical tube and place on ice.
5. Repeat steps 2 to 4 until all the tissue is processed into a homogenous suspension.
6. If more grinding is necessary, add more PBS + PIC to tissue. Repeat steps 2 to 5 until all tissue is ground into a homogeneous suspension.
7. Check for single-cell suspension by microscope (optional).
8. Centrifuge cells at 1,500 rpm in a bench top centrifuge for 5 min at 4°C.
9. Remove supernatant from cells and immediately continue with Nuclei Preparation and Chromatin Digestion (Section III).

C. Tissue Disaggregation Using a Dounce Homogenizer

1. Transfer tissue resuspended in PBS + PIC to a Dounce homogenizer.
2. Disaggregate tissue pieces with 20-25 strokes. Check for single-cell suspension by microscope (optional).
3. Transfer cell suspension to a 15 ml conical tube and centrifuge at 1,500 rpm in a benchtop centrifuge for 5 min at 4°C.
4. Remove supernatant from cells and immediately continue with Nuclei Preparation and Chromatin Digestion (Section III).

II. Cell Culture Cross-linking and Sample Preparation

For optimal ChIP results, use approximately 4 X 10⁶ cells for each immunoprecipitation to be performed. For HeLa cells, this is equivalent to half of a 15 cm culture dish containing cells that are 90% confluent in 20 ml of growth medium. One additional sample should be processed for Analysis of Chromatin Digestion and Concentration (Section IV). Include one extra dish of cells in experiment to be used for determination of cell number using a hemocytometer.

Before starting

• Remove and warm 200X Protease Inhibitor Cocktail (PIC) #7012 and 10X Glycine Solution #7005. Make sure PIC is completely thawed.
• Prepare 2 ml of Phosphate Buffered Saline (PBS) + 10 µl 200X PIC per 15 cm dish to be processed and place on ice.
• Prepare 40 ml of PBS per 15 cm dish to be processed and place on ice.
• Prepare 540 µl of 37% formaldehyde per 15 cm dish of cells to be processed and keep at room temperature. Use fresh formaldehyde that is not past the manufacturer's expiration date.

1. To crosslink proteins to DNA, add 540 µl of 37% formaldehyde to each 15 cm culture dish containing 20 ml medium. Swirl briefly to mix and incubate 10 min at room temperature. Final formaldehyde concentration is 1%. Addition of formaldehyde may result in a color change of the medium.
2. Add 2 ml of 10X glycine to each 15 cm dish containing 20 ml medium, swirl briefly to mix, and incubate 5 min at room temperature. Addition of glycine may result in a color change of the medium.
3. For suspension cells, transfer cells to a 50 ml conical tube, centrifuge at 1,500 rpm in a benchtop centrifuge 5 min at 4°C and wash pellet two times with 20 ml ice-cold PBS. Remove supernatant and immediately continue with Nuclei Preparation and Chromatin Digestion (Section III).
4. For adherent cells, remove media and wash cells two times with 20 ml ice-cold 1X PBS, completely removing wash from culture dish each time.
5. Add 2 ml ice-cold PBS + PIC to each 15 cm dish. Scrape cells into cold buffer. Combine cells from all culture dishes into one 15 ml conical tube.
6. Centrifuge cells at 1,500 rpm in a benchtop centrifuge for 5 min at 4°C. Remove supernatant and immediately continue with Nuclei Preparation and Chromatin Digestion (Section III).

III. Nuclei Preparation and Chromatin Digestion

One immunoprecipitation preparation (IP prep) is defined as 25 mg of disaggregated tissue or 4 x 10⁶ tissue culture cells.

Before starting

• Remove and warm 200X Protease Inhibitor Cocktail (PIC) #7012. Make sure it is completely thawed prior to use.

• Prepare 1 M DTT (192.8 mg DTT #7016 + 1.12ml dH₂O). Make sure DTT crystals are completely in solution.

  IMPORTANT: Once in solution, store 1M DTT at -20°C.

• Remove and warm 10X ChIP Buffer #7008 and ensure SDS is completely in solution.
• Prepare 1 ml 1X Buffer A (250 µl 4X Buffer A #7006 + 750 µl water) + 0.5 µl 1M DTT + 5 µl 200X PIC per IP prep and place on ice.
• Prepare 1.1 ml 1X Buffer B (275 µl 4X Buffer B #7007 + 825 µl water) + 0.55 µl 1M DTT per IP prep and place on ice.
• Prepare 100 µl 1X ChIP Buffer (10 µl 10X ChIP Buffer #7008 + 90 µl water) + 0.5 µl 200X PIC per IP prep and place on ice.

1. Resuspend cells in 1 ml ice-cold 1X Buffer A + DTT + PIC per IP prep. Incubate on ice for 10 min. Mix by inverting tube every 3 min.
2. Pellet nuclei by centrifugation at 3,000 rpm in a benchtop centrifuge for 5 min at 4°C. Remove supernatant and resuspend pellet in 1 ml ice-cold 1X Buffer B + DTT per IP prep. Repeat centrifugation, remove supernatant, and resuspend pellet in 100 µl 1X Buffer B +DTT per IP prep. Transfer sample to a 1.5 ml microcentrifuge tube, up to 1 ml total per tube.
3. Add 0.5 µl of Micrococcal Nuclease #10011 per IP prep, mix by inverting tube several times and incubate for 20 min at 37°C with frequent mixing to digest DNA to length of approximately 150-900 bp. Mix by inversion every 3 to 5 min. The amount of Micrococcal Nuclease required to digest DNA to the optimal length may need to be determined empirically for individual tissues and cell lines (see Appendix B). HeLa nuclei digested with 0.5 µl Micrococcal Nuclease per 4 x 10⁶ cells and mouse liver tissue digested with 0.5 µl Micrococcal Nuclease per 25 mg of tissue gave the appropriate length DNA fragments.
4. Stop digest by adding 10 µl of 0.5 M EDTA #7011 per IP prep and placing tube on ice.
5. Pellet nuclei by centrifugation at 13,000 rpm in a microcentrifuge for 1 min at 4°C and remove supernatant.
6. Resuspend nuclear pellet in 100 µl of 1X ChIP Buffer + PIC per IP prep and incubate on ice for 10 min.
7. Sonicate up to 500 µl of lysate per 1.5 ml microcentrifuge tube with several pulses to break nuclear membrane. Incubate samples for 30 sec on wet ice between pulses. Optimal conditions required for complete lysis of nuclei can be determined by observing nuclei under light microscope before and after sonication. HeLa nuclei were completely lysed after 3 sets of 20-sec pulses using a VirTis Virsonic 100 Ultrasonic Homogenizer/Sonicator at setting 6 with a 1/8-inch probe. Alternatively, nuclei can be lysed by homogenizing the lysate 20 times in a Dounce homogenizer; however, lysis may not be as complete.
8. Clarify lysates by centrifugation at 10,000 rpm in a microcentrifuge for 10 min at 4°C.
9. Transfer supernatant to a new tube. This is the cross-linked chromatin preparation, which should be stored at -80°C until further use. Remove 50 µl of the chromatin preparation for Analysis of Chromatin Digestion and Concentration (Section IV).

IV. Analysis of Chromatin Digestion and Concentration (Recommended Step)

1. To the 50 µl chromatin sample (from Step 9 in Section III), add 100 µl nuclease-free water, 6 µl 5 M NaCl #7010, and 2 µl RNAse A #7013. Vortex to mix and incubate samples at 37°C for 30 min.
2. To each RNAse A-digested sample, add 2 µl Proteinase K. Vortex to mix and incubate samples at 65°C for 2 h.
3. Purify DNA from samples using DNA purification spin columns as described in Section VII.
4. After purification of DNA, remove a 10 µl sample and determine DNA fragment size by electrophoresis on a 1% agarose gel with a 100 bp DNA marker. DNA should be digested to a length of approximately 150-900 bp (1 to 5 nucleosomes).
5. To determine DNA concentration, transfer 2 µl of purified DNA to 98 µl nuclease-free water to give a 50-fold dilution and read the OD₂₆₀. The concentration of DNA in µg/ml is OD₂₆₀ x 2,500. DNA concentration should ideally be between 50 and 200 µg/ml.

NOTE: For optimal ChIP results, it is highly critical that the chromatin is of appropriate size and concentration. Over-digestion of chromatin may diminish signal in the PCR quantification. Under-digestion of chromatin may lead to increased background signal and lower resolution. Adding too little chromatin to the IP may result in diminished signal in the PCR quantification. A protocol for optimization of chromatin digestion can be found in Appendix B.

V. Chromatin Immunoprecipitation

For optimal ChIP results, use approximately 5 to 10 µg of digested, cross-linked chromatin (as determined in Section IV) per immunoprecipitation. This should be roughly equivalent to a single 100 µl IP prep from 25 mg of disaggregated tissue or 4 x 10⁶ tissue culture cells. Typically, 100 µl of digested chromatin is diluted into 400 µl 1X ChIP Buffer prior to the addition of antibodies. However, if more than 100 µl of chromatin is required per IP, the cross-linked chromatin preparation does not need to be diluted as described below. Antibodies can be added directly to the undiluted chromatin preparation for immunoprecipitation of chromatin complexes.

Before starting

• Remove and warm 200X Protease Inhibitor Cocktail (PIC) #7012. Make sure PIC is completely thawed.
• Remove and warm 10X ChIP Buffer #7008 and ensure SDS is completely in solution.
• Thaw digested chromatin preparation (from Step 9 in Section III) and place on ice.
• Prepare low salt wash: 3 ml 1X ChIP Buffer (300 µl 10X ChIP Buffer #7008 + 2.7 ml water) per immunoprecipitation. Store at room temperature until use.
• Prepare high salt wash: 1 ml 1X ChIP Buffer (100 µl 10X ChIP Buffer #7008 + 900 µl water) + 70 µl 5M NaCl #7010 per immunoprecipitation. Store at room temperature until use.

1. In one tube, prepare enough 1X ChIP Buffer for the dilution of digested chromatin into the desired number of immunoprecipitations: 400 µl of 1X ChIP Buffer (40 µl of 10X ChIP Buffer + 360 µl water) + 2 µl 200X PIC per immunoprecipitation. When determining the number of immunoprecipitations, remember to include the positive control Histone H3 (D2B12) XP^® Rabbit mAb #4620 and negative control Normal Rabbit IgG antibody #2729 samples. Place mix on ice.
2. To the prepared 1X ChIP Buffer, add the equivalent of 100 µl (5 to 10 µg of chromatin) of the digested, cross-linked chromatin preparation (from Step 9 in Section III) per immunoprecipitation. For example, for 10 immunoprecipitations, prepare a tube containing 4 ml 1X ChIP Buffer (400 µl 10X ChIP Buffer + 3.6 ml water) + 20 µl 200X PIC + 1 ml digested chromatin preparation.
3. Remove a 10 µl sample of the diluted chromatin and transfer to a microfuge tube. This is your 2% Input Sample, which can be stored at -20°C until further use (Step 1 in Section VI).
4. For each immunoprecipitation, transfer 500 µl of the diluted chromatin to a 1.5 ml microcentrifuge tube and add the immunoprecipitating antibody. The amount of antibody required per IP varies and should be determined by the user. For the positive control Histone H3 (D2B12) XP^® Rabbit mAb #4620, add 10 µl to the IP sample. For the negative control Normal Rabbit IgG #2729, add 1 µl (1 µg) to 2 µl (2 µg) to the IP sample. Incubate IP samples 4 h to overnight at 4°C with rotation.

NOTE: Most antibodies from Cell Signaling Technology work optimally between 1 and 2 ug per IP sample. In the case where there are multiple samples with varying concentrations, it is best to match the negative control Normal Rabbit IgG #2729 to the highest antibody concentration.

5. Resuspend ChIP-Grade Protein G Magnetic Beads #9006 by gently vortexing. Immediately add 30 µl of Protein G Magnetic Beads to each IP reaction and incubate for 2 h at 4°C with rotation.
6. Pellet protein G magnetic beads in each immunoprecipitation by placing the tubes in a magnetic separation rack #7017. Wait 1 to 2 min for solution to clear and then carefully remove supernatant.
7. Wash protein G magnetic beads by adding 1 ml of low salt wash to the beads and incubate at 4°C for 5 min with rotation. Repeat steps 6 and 7 two additional times for a total of 3 low salt washes.
8. Add 1 ml of high salt wash to the beads and incubate at 4°C for 5 min with rotation.
9. Pellet protein G magnetic beads in each immunoprecipitation by placing the tubes in a Magnetic Separation Rack. Wait 1 to 2 min for solution to clear and then carefully remove supernatant. Immediately proceed to Section VI.

VI. Elution of Chromatin from Antibody/Protein G Magnetic Beads and Reversal of Cross-links

Before starting

• Remove and warm 2X ChIP Elution Buffer #7009 in a 37°C water bath and ensure SDS is in solution.
• Set a water bath or thermomixer to 65°C.
• Prepare 150 µl 1X ChIP Elution Buffer (75 µl 2X ChIP Elution Buffer #7009 + 75 µl water) for each immunoprecipitation and the 2% input sample.

1. Add 150 µl of the 1X ChIP Elution Buffer to the 2% input sample tube and set aside at room temperature until Step 6.
2. Add 150 µl 1X ChIP Elution Buffer to each IP sample.
3. Elute chromatin from the antibody/protein G magnetic beads for 30 min at 65°C with gentle vortexing (1,200 rpm). A thermomixer works best for this step. Alternatively, elutions can be performed at room temperature with rotation, but may not be as complete.
4. Pellet protein G magnetic beads by placing the tubes in a magnetic separation rack and wait 1 to 2 min for solution to clear.
5. Carefully transfer eluted chromatin supernatant to a new tube.
6. To all tubes, including the 2% input sample from Step 1, reverse cross-links by adding 6 µl 5M NaCl and 2 µl Proteinase K #10012, and incubate 2 h at 65°C. This incubation can be extended overnight.
7. Immediately proceed to Section VII. Alternatively, samples can be stored at -20°C. However, to avoid formation of a precipitate, be sure to warm samples to room temperature before adding DNA Binding Buffer #10007 (Section VII, Step 1).

VII. DNA Purification Using Spin Columns

Before starting

• Add 24 ml of ethanol (96-100%) to DNA Wash Buffer #10008 before use. This step only has to be performed once prior to the first set of DNA purifications.
• Remove one DNA Purification collection tube #10010 for each DNA sample from Section V.

1. Add 750 µl DNA Binding Buffer #10007 to each DNA sample and vortex briefly.
   • 5 volumes of DNA Binding Buffer should be used for every 1 volume of sample.
2. Transfer 450 µl of each sample from Step 1 to a DNA spin column in collection tube.
3. Centrifuge at 14,000 rpm in a microcentrifuge for 30 sec.
4. Remove the spin column from the collection tube and discard the liquid. Replace spin column in the collection tube.
5. Transfer the remaining 450 µl of each sample from Step 1 to the spin column in collection tube. Repeat Steps 3 and 4.
6. Add 750 µl of DNA Wash Buffer #10008 to the spin column in collection tube.
7. Centrifuge at 14,000 rpm in a microcentrifuge for 30 sec.
8. Remove the spin column from the collection tube and discard the liquid. Replace spin column in the collection tube.
9. Centrifuge at 14,000 rpm in a microcentrifuge for 30 sec.
10. Discard collection tube and liquid. Retain spin column.
11. Add 50 µl of DNA Elution Buffer #10009 to each spin column and place into a clean 1.5 ml microcentrifuge tube.
12. Centrifuge at 14,000 rpm in a microcentrifuge for 30 sec to elute DNA.
13. Remove and discard DNA spin column. Eluate is now purified DNA. Samples can be stored at -20°C.

VIII. Quantification of DNA by PCR

Recommendations

• Use Filter-tip pipette tips to minimize risk of contamination.
• The control primers included in the kit are specific for the human or mouse RPL30 gene (#7014 + #7015) and can be used for either standard PCR or quantitative real-time PCR. If the user is performing ChIPs from another species, it is recommended that the user design the appropriate specific primers to DNA and determine the optimal PCR conditions.
• A Hot-Start Taq polymerase is recommended to minimize the risk of nonspecific PCR products.
• PCR primer selection is critical. Primers should be designed with close adherence to the following criteria:

Standard PCR Method

1. Label the appropriate number of 0.2 ml PCR tubes for the number of samples to be analyzed. These should include the 2% input sample, the positive control histone H3 sample, the negative control normal rabbit IgG sample, and a tube with no DNA to control for DNA contamination.
2. Add 2 µl of the appropriate DNA sample to each tube.
3. Prepare a master reaction mix as described below, making sure to add enough reagent for two extra tubes to account for loss of volume. Add 18 µl of master mix to each reaction tube.

4. Start the following PCR reaction program:

5. Remove 10 µl of each PCR product for analysis by 2% agarose gel or 10% polyacrylamide gel electrophoresis with a 100 bp DNA marker. The expected size of the PCR product is 161 bp for human RPL30 #7014 and 159 bp for mouse RPL30 #7015.

Real-Time Quantitative PCR Method

1. Label the appropriate number of PCR tubes or PCR plates compatible with the model of PCR machine to be used. PCR reactions should include the positive control histone H3 sample, the negative control normal rabbit IgG sample, a tube with no DNA to control for contamination, and a serial dilution of the 2% input chromatin DNA (undiluted, 1:5, 1:25, 1:125) to create a standard curve and determine the efficiency of amplification.
2. Add 2 µl of the appropriate DNA sample to each tube or well of the PCR plate.
3. Prepare a master reaction mix as described below. Add enough reagents for two extra reactions to account for loss of volume. Add 18 µl of reaction mix to each PCR reaction tube or well.

4. Start the following PCR reaction program:

5. Analyze quantitative PCR results using the software provided with the real-time PCR machine. Alternatively, one can calculate the IP efficiency manually using the Percent Input Method and the equation shown below. With this method, signals obtained from each immunoprecipitation are expressed as a percent of the total input chromatin.

   Percent Input = 2% x 2^{(C[T] 2%Input Sample - C[T] IP Sample)}

   C[T] = C_T = Threshold cycle of PCR reaction

IX. NG-Sequencing Library Construction

The immuno-enriched DNA samples prepared with this kit are directly compatible with ChIP-seq. For downstream NG-sequencing DNA library construction, use a DNA library preparation protocol or kit compatible with your downstream sequencing platform. For sequencing on Illumina^® platforms, we recommend NEBNext^® Ultra^™ II Library Prep Kit for Illumina^® (New England Biolabs; Cat #E7645S/L).

Recommendations:

• For transcription factor or co-factor ChIP-seq, use at least 5 ng of ChIP-enriched DNA and amplification of the adaptor-ligated DNA with 10 cycles of PCR.
• For total histone and histone modifications, or input samples, start with 50 ng of ChIP-enriched DNA and amplification of the adaptor-ligated DNA with 6 cycles of PCR.
• For library construction of ChIP-enriched DNA for all target types, perform cleanup of adaptor-ligated DNA without size selection.
• After DNA library construction, check the DNA library for presence of adaptor dimers (~140 bp) using an Agilent High Sensitivity DNA Kit (Agilent Technologies, Cat# G2938-90322), or by agarose gel electrophoresis with 50-100 ng DNA on a 2% agarose TAE gel. If adaptor dimers are present in the DNA library, repeat cleanup of PCR amplified material.
• The quality of the library can also be confirmed using qPCR and primer sets to known positive and negative target loci. Positive primer pairs should still give the same high signal compared to negative primers as seen in the original qPCR analysis of ChIP-enriched DNA.
• After final cleanup and quality checks, prepare final purified library samples at 2-10 nM for high throughput sequencing.

APPENDIX A: Expected Chromatin Yield

When harvesting cross-linked chromatin from tissue samples, the yield of chromatin can vary significantly between tissue types. The table to the right provides a range for the expected yield of chromatin from 25 mg of tissue compared to 4 x 10⁶ HeLa cells, and the expected DNA concentration, as determined in Section IV of the protocol. For each tissue type, disaggregation using a Medimachine (BD Biosciences) or a Dounce homogenizer yielded similar amounts of chromatin. However, chromatin processed from tissues disaggregated using the Medimachine typically gave higher IP efficiencies than chromatin processed from tissues disaggregated using a Dounce homogenizer. A Dounce homogenizer is strongly recommended for disaggregation of brain tissue, as the Medimachine does not adequately disaggregate brain tissue into a single-cell suspension. For optimal ChIP results, we recommend using 5 to 10 µg of digested, cross-linked chromatin per immunoprecipitation; therefore, some tissues may require harvesting more than 25 mg per each immunoprecipitation.

APPENDIX B: Optimization of Chromatin Digestion

Optimal conditions for the digestion of cross-linked chromatin DNA to 150-900 base pairs in length is highly dependent on the ratio of Micrococcal Nuclease to the amount of tissue or number of cells used in the digest. Below is a protocol for determination of the optimal digestion conditions for a specific tissue or cell type.

1. Prepare cross-linked nuclei from 125 mg of tissue or 2 X 10⁷ cells (equivalent of 5 IP preps), as described in Sections I, II, and III. Stop after Step 2 of Section III and proceed as described below.
2. Transfer 100 µl of the nuclei preparation into 5 individual 1.5 ml microcentrifuge tubes and place on ice.
3. Add 3 µl Micrococcal Nuclease stock to 27 µl of 1X Buffer B + DTT (1:10 dilution of enzyme).
4. To each of the 5 tubes in Step 2, add 0 µl, 2.5 µl, 5 µl, 7.5 µl, or 10 µl of the diluted Micrococcal Nuclease, mix by inverting tube several times and incubate for 20 min at 37°C with frequent mixing.
5. Stop each digest by adding 10 µl of 0.5 M EDTA and placing tubes on ice.
6. Pellet nuclei by centrifugation at 13,000 rpm in a microcentrifuge for 1 min at 4°C and remove supernatant.
7. Resuspend nuclear pellet in 200 µl of 1X ChIP Buffer + PIC. Incubate on ice for 10 min.
8. Sonicate lysate with several pulses to break nuclear membrane. Incubate samples 30 sec on wet ice between pulses. Optimal conditions required for complete lysis of nuclei can be determined by observing nuclei under light microscope before and after sonication. HeLa nuclei were completely lysed after 3 sets of 20-sec pulses using a VirTis Virsonic 100 Ultrasonic Homogenizer/Sonicator set at setting 6 with a 1/8-inch probe. Alternatively, nuclei can be lysed by homogenizing the lysate 20 times in a Dounce homogenizer; however, lysis may not be as complete.
9. Clarify lysates by centrifugation at 10,000 rpm in a microcentrifuge for 10 min at 4°C.
10. Transfer 50 µl of each of the sonicated lysates to new microfuge tubes.
11. To each 50 µl sample, add 100 µl nuclease-free water, 6 µl 5 M NaCl and 2 µl RNAse A. Vortex to mix and incubate samples at 37°C for 30 min.
12. To each RNAse A-digested sample, add 2 µl Proteinase K. Vortex to mix and incubate sample at 65°C for 2 h.
13. Remove 20 µl of each sample and determine DNA fragment size by electrophoresis on a 1% agarose gel with a 100 bp DNA marker.
14. Observe which of the digestion conditions produces DNA in the desired range of 150-900 base pairs (1 to 5 nucleosomes). The volume of diluted Micrococcal Nuclease that produces the desired size of DNA fragments using this optimization protocol is equivalent to 10 times the volume of Micrococcal Nuclease stock that should be added to one immunoprecipitation preparation (25 mg of disaggregated tissue cells or 4 X 10⁶ tissue culture cells) to produce the desired size of DNA fragments. For example, if 5 µl of diluted Micrococcal Nuclease produces DNA fragments of 150-900 base pairs in this protocol, then 0.5 µl of stock Micrococcal Nuclease should be added to one IP prep during the digestion of chromatin in Section III.
15. If results indicate that DNA is not in the desired size range, then repeat optimization protocol, adjusting the amount of Micrococcal Nuclease in each digest accordingly. Alternatively, the digestion time can be changed to increase or decrease the extent of DNA fragmentation.

APPENDIX C: Troubleshooting Guide
