p16 INK4A (BC42) Mouse mAb
Primary Antibodies
Monoclonal Antibody

p16 INK4A (BC42) Mouse mAb #68410

Reviews ()
Citations (0)
Filter:
  1. IHC
Immunohistochemistry Image 1: p16 INK4A (BC42) Mouse mAb
Immunohistochemical analysis of paraffin-embedded human squamous cell carcinoma of the cervix using p16 INK4A (BC42) Mouse mAb performed on the Leica BOND Rx.
Immunohistochemistry Image 1: p16 INK4A (BC42) Mouse mAb
Immunohistochemical analysis of paraffin-embedded human papillary thyroid carcinoma using p16 INK4A (BC42) Mouse mAb.
Immunohistochemistry Image 2: p16 INK4A (BC42) Mouse mAb
Immunohistochemical analysis of paraffin-embedded human squamous cell carcinoma of the cervix using p16 INK4A (BC42) Mouse mAb.
Immunohistochemistry Image 3: p16 INK4A (BC42) Mouse mAb
Immunohistochemical analysis of paraffin-embedded human prostate adenocarcinoma using p16 INK4A (BC42) Mouse mAb.
Immunohistochemistry Image 4: p16 INK4A (BC42) Mouse mAb
Immunohistochemical analysis of paraffin-embedded human ovarian serous adenocarcinoma using p16 INK4A (BC42) Mouse mAb.
Immunohistochemistry Image 5: p16 INK4A (BC42) Mouse mAb
Immunohistochemical analysis of paraffin-embedded human B-cell non-Hodgkin lymphoma using p16 INK4A (BC42) Mouse mAb.
Immunohistochemistry Image 6: p16 INK4A (BC42) Mouse mAb
Immunohistochemical analysis of paraffin-embedded human mantle cell lymphoma using p16 INK4A (BC42) Mouse mAb.
Immunohistochemistry Image 7: p16 INK4A (BC42) Mouse mAb
Immunohistochemical analysis of paraffin-embedded human ductal breast carcinoma using p16 INK4A (BC42) Mouse mAb.
Immunohistochemistry Image 8: p16 INK4A (BC42) Mouse mAb
Immunohistochemical analysis of paraffin-embedded normal human pancreas using p16 INK4A (BC42) Mouse mAb.
Immunohistochemistry Image 9: p16 INK4A (BC42) Mouse mAb
Immunohistochemical analysis of paraffin-embedded normal human prostate using p16 INK4A (BC42) Mouse mAb.
Immunohistochemistry Image 10: p16 INK4A (BC42) Mouse mAb
Immunohistochemical analysis of paraffin-embedded human prostate adenocarcinoma using p16 INK4A (BC42) Mouse mAb (left) compared to concentration-matched Mouse (G3A1) mAb IgG1 Isotype Control #5415 (right).
Immunohistochemistry Image 11: p16 INK4A (BC42) Mouse mAb
Immunohistochemical analysis of paraffin-embedded HeLa cell pellet (left, positive) or MCF7 cell pellet (right, negative) using p16 INK4A (BC42) Mouse mAb.
To Purchase # 68410
Cat. # Size Qty. Price
68410T
20 µl
$ 138
68410S
100 µl
$ 313

Supporting Data

REACTIVITY H
SENSITIVITY Endogenous
MW (kDa)
Source/Isotype Mouse IgG1 kappa

Application Key:

  • WB-Western Blot
  • IP-Immunoprecipitation
  • IHC-Immunohistochemistry
  • ChIP-Chromatin Immunoprecipitation
  • C&R-CUT&RUN
  • C&T-CUT&Tag
  • DB-Dot Blot
  • eCLIP-eCLIP
  • IF-Immunofluorescence
  • F-Flow Cytometry

Species Cross-Reactivity Key:

  • H-Human
  • M-Mouse
  • R-Rat
  • Hm-Hamster
  • Mk-Monkey
  • Vir-Virus
  • Mi-Mink
  • C-Chicken
  • Dm-D. melanogaster
  • X-Xenopus
  • Z-Zebrafish
  • B-Bovine
  • Dg-Dog
  • Pg-Pig
  • Sc-S. cerevisiae
  • Ce-C. elegans
  • Hr-Horse
  • GP-Guinea Pig
  • Rab-Rabbit
  • All-All Species Expected

Product Usage Information

Application Dilution
IHC Leica Bond 1:50 - 1:200
Immunohistochemistry (Paraffin) 1:50

Storage

Supplied in a Tris-based buffer with ~1% BSA and less than 0.1% sodium azide. Stable for 6 months when stored at 4°C. Do not aliquot the antibody.

Protocol

PRINT

View >Collapse >

Immunohistochemistry (Leica®BOND™)

NOTE: Please see product datasheet or product webpage for appropriate antibody dilution^.

  Step Reagents Time/Temperature
1 Dewax BOND™ Dewax Solution, 100% Alcohol, BOND™ Wash Solution Pre-programmed Leica® BOND™
2 Antigen Retrieval  BOND™ Epitope Retrieval ER2 Solution 20 min., 100˚C | Protocol: HIER 20 min with ER2
3 Peroxide Block Polymer Refine Detection Kit Peroxide Block* 5 min.
  WASH BOND™ Wash Solution  3x 0:00 min.
4 Protein Block (optional) #5425 NGS or #15019 Animal-Free Blocking Solution   20 min.
5 Primary Antibody^ Dilute in #8112 SignalStain® Antibody Diluent 30 min.
  WASH BOND™ Wash Solution  3x 2:00 min.
6 Post Primary Mouse Linker Polymer Refine Detection Kit Post Primary*  10 min.
  WASH BOND™ Wash Solution  3x 2:00 min.
7 Secondary Detection Polymer Refine Detection Kit Polymer*  10 min.
  WASH BOND™ Wash Solution/Deionized Water Custom (see below)
8a Visualization Polymer Refine Detection Kit Mixed DAB Refine*  0:00 min.
8b Visualization Polymer Refine Detection Kit Mixed DAB Refine*  10 min.
  WASH Deionized Water 3x 0:00 min.
9 Counterstain Polymer Refine Detection Kit Hematoxylin*  5 min.
  WASH Deionized Water 0:00 min.
  WASH BOND™ Wash Solution  0:00 min.
  WASH Deionized Water 0:00 min.
10 Dehydration (Offline):
  Incubate sections in 95% ethanol two times for 10 seconds each.
  Repeat in 100% ethanol, incubating sections two times for 10 seconds each.
  Repeat in xylene, incubating sections two times for 10 seconds each.
11 Mount sections with coverslips and #14177 SignalStain® Mounting Medium

  Optional Custom wash:  BOND™ Wash Solution 2:00
    BOND™ Wash Solution Dispenser Type: OPEN 0:00
    BOND™ Wash Solution 2:00
    BOND™ Wash Solution Dispenser Type: OPEN 0:00
    BOND™ Wash Solution 0:00
    Deionized Water 0:00

*Reagent included in BOND™ Polymer Refine Detection Kit (Catalog No: DS9800)

LEICA® is a registered trademark of Leica Microsystems IR GmbH.

BOND™ is a trademark of Leica Biosystems Melbourne Pty. Ltd. No affiliation or sponsorship between CST and Leica Microsystems IR GmbH or Leica Biosystems Melbourne Pty. Ltd is implied.

posted August 2018

revised September 2018

Protocol Id: 1445

Immunohistochemistry (Paraffin)

A. Solutions and Reagents

NOTE: Prepare solutions with reverse osmosis deionized (RODI) or equivalent grade water.

  1. Xylene.
  2. Ethanol, anhydrous denatured, histological grade (100% and 95%).
  3. Deionized water (dH2O).
  4. Hematoxylin (optional).
  5. Wash Buffer:
    1. 1X Tris Buffered Saline with Tween® 20 (TBST): To prepare 1L 1X TBST add 100 ml 10X Tris Buffered Saline with Tween® 20 (#9997) to 900 ml dH20, mix.
  6. SignalStain® Antibody Diluent (#8112).
  7. 1X Citrate Unmasking Solution: To prepare 250 mL of 1X citrate unmasking solution, dilute 25 ml of SignalStain® Citrate Unmasking Solution (10X) (#14746) with 225 mL of dH2O.
  8. 3% Hydrogen Peroxide: To prepare 100 ml, add 10 ml 30% H2O2 to 90 ml dH2O.
  9. Blocking Solution: TBST/5% Normal Goat Serum or 1X Animal-Free Blocking Solution.
    1. TBST/5% Normal Goat Serum: to 5 ml 1X TBST, add 250 µl Normal Goat Serum (#5425).
    2. 1X Animal-Free Blocking Solution: to 4 mL of dH2O add 1 ml of Animal-Free Blocking Solution (5X) (#15019).
  10. Detection System: SignalStain® Boost IHC Detection Reagents (HRP, Mouse #8125).
  11. Substrate: SignalStain® DAB Substrate Kit (#8059).
  12. Hematoxylin: Hematoxylin (#14166).
  13. Mounting Medium: SignalStain® Mounting Medium (#14177).

B. Deparaffinization/Rehydration

NOTE: Do not allow slides to dry at any time during this procedure.

  1. Deparaffinize/hydrate sections:
    1. Incubate sections in three washes of xylene for 5 min each.
    2. Incubate sections in two washes of 100% ethanol for 10 min each.
    3. Incubate sections in two washes of 95% ethanol for 10 min each.
  2. Wash sections two times in dH2O for 5 min each.

C. Antigen Unmasking

For Citrate: Heat slides in a microwave submersed in 1X citrate unmasking solution until boiling is initiated; follow with 10 min at a sub-boiling temperature (95°-98°C). Cool slides on bench top for 30 min.

D. Staining

  1. Wash sections in dH2O three times for 5 min each.
  2. Incubate sections in 3% hydrogen peroxide for 10 min.
  3. Wash sections in dH2O two times for 5 min each.
  4. Wash sections in wash buffer for 5 min.
  5. Block each section with 100–400 µl of preferred blocking solution for 1 hr at room temperature.
  6. Remove blocking solution and add 100–400 µl primary antibody diluted in SignalStain® Antibody Diluent (#8112) to each section. Incubate overnight at 4°C.
  7. Equilibrate SignalStain® Boost Detection Reagent (HRP, Mouse #8125) to room temperature.
  8. Remove antibody solution and wash sections with wash buffer three times for 5 min each.
  9. Cover section with 1–3 drops SignalStain® Boost Detection Reagent (HRP, Mouse #8125) as needed. Incubate in a humidified chamber for 30 min at room temperature.
  10. Wash sections three times with wash buffer for 5 min each.
  11. Add 1 drop (30 µl) SignalStain® DAB Chromogen Concentrate to 1 ml SignalStain® DAB Diluent and mix well before use.
  12. Apply 100–400 µl SignalStain® DAB to each section and monitor closely. 1–10 min generally provides an acceptable staining intensity.
  13. Immerse slides in dH2O.
  14. If desired, counterstain sections with hematoxylin (#14166).
  15. Wash sections in dH2O two times for 5 min each.
  16. Dehydrate sections:
    1. Incubate sections in 95% ethanol two times for 10 sec each.
    2. Repeat in 100% ethanol, incubating sections two times for 10 sec each.
    3. Repeat in xylene, incubating sections two times for 10 sec each.
  17. Mount sections with coverslips and mounting medium (#14177).

DETECTION REAGENT/SUBSTRATE COMPATIBILITY
RECOMMENDED
DETECTION REAGENTS
SignalStain® Boost IHC Detection Reagent (HRP, Mouse) #8125 SignalStain® Boost IHC Detection Reagent (AP, Mouse) #31926
COMPATIBLE
CHROMOGEN
SignalStain® DAB Substrate Kit #8059 SignalStain® Vibrant Red Alkaline Phosphatase Substrate Kit #76713
SignalStain® Vivid Purple Peroxidase Substrate Kit #96632

NOTE: Use of detection reagents other than those specified in this protocol may require further optimization of the primary antibody to account for the different sensitivities of the detection reagents.


posted February 2010

revised June 2020

Protocol Id: 280

Specificity / Sensitivity

p16 INK4A (BC42) Mouse mAb recognizes endogenous levels of total p16 INK4A protein.

Species Reactivity:

Human

Source / Purification

Monoclonal antibody is produced by immunizing animals with a prokaryotic recombinant protein corresponding to the p16 INK4A region of the p16 molecule.

Background

Members of the INK4 family of cyclin dependent kinase inhibitors include p16 INK4A, p15 INK4B, p18 INK4C, and p19 INK4D. The INK4 family members inhibit cyclin dependent kinases 4 and 6 (CDK4 and CDK6), causing cell cycle arrest in G1 phase. The INK4A-ARF-INK4B locus on chromosome 9p21, frequently lost in human cancer, encodes the INK4 family members p16 INK5A and p15 INK4B, as well as the unrelated protein, ARF (1).

p16 INK4A expression, typically repressed in the absence of stress, is thought to drive cells into senescence, and p16 INK4A expression is a commonly used marker of senescent cells (2,3). p16 INK4A protein expression is often altered in human cancer, and high expression is currently used as a predictive biomarker in cervical cancer (3-5).
  1. Kim, W.Y. and Sharpless, N.E. (2006) Cell 127, 265-75.
  2. LaPak, K.M. and Burd, C.E. (2014) Mol Cancer Res 12, 167-83.
  3. Romagosa, C. et al. (2011) Oncogene 30, 2087-97.
  4. Ishikawa, M. et al. (2006) Int J Gynecol Cancer 16, 347-53.
  5. Queiroz, C. et al. (2006) Pathol Res Pract 202, 77-83.
